Agilent Technologies 8753ET Service Guide

2-132 Chapter 2
System Verification and Performance Tests
Agilent 8753ET System Verification and Performance Tests
Procedure
First Enhanced Response Calibration
1. Refer to Figure 2-74 when performing steps 2 through 10.
Figure 2-74 First Enhanced Response Calibration
2. Press .
3. Press
.
4. Press .
5. Connect the OPEN (supplied in the calibration kit) to the analyzer’s reflection test port.
6. Press .
7. Connect the SHORT to the reflection test port.
8. Press .
9. Connect the 50 ohm termination (supplied in the calibration kit) to the reflection test
port.
10.Press .
Preset Avg
IF BW
3
k/m
Start 300 k/m
Cal
CAL KIT
SELECT CAL KIT
N 50
Ω
85032
RETURN
RETURN
CALIBRATE MENU
ENHANCED RESPONSE
TRAN/REFL ENH. RESP.
ISOLATION
OMIT ISOLATION
REFLECTION
FORWARD:OPENS
OPEN(F)
DONE: OPENS
FORWARD:SHORTS
SHORT(F)
DONE: SHORTS
FORWARD:LOAD
STANDARDS DONE
