Chapter 7 231
Digital Signal Interface Module
Connecting the Clock Source and the Device Under Test
1. Refer to the five setup diagrams in Figure 7-3 on page 222 and connect the frequency reference cable
according to the clock source.
2. If an external clock source is used, connect the external clock signal to the Ext Clock In connector on the
interface module.
3. Select the break-out board that has the output connector suited for the application.
NOTE If the Device Interface mating connector is used with the device under test, refer to Figure
7-8 for the device interface connection and connect the device to the N5102A module. Then
proceed to “Operating the N5102A Module in Output Mode” on page 234 or “Operating
the N5102A Module in Input Mode” on page 243.
4. Refer to Figure 7-8. Connect the break-out board to the Device Interface connector on the N5102A
module.
5. Connect the device to the break-out board.
