AIREDALE DeltaChill - Page 108

Chillers
DeltaChill™ Air Cooled and FreeCool
108
Chiller Technical Manual 7267818 V1.13.0_01_2018
Technic al FreeCool
ELECTRICAL DATA 7 8 9
Unit Data DCF053DR-10DPV0 DCF055DR-09DYV0 DCF055DR-10DYY0
Nominal Run Amps (1) A 339.4 361.5 341.1
Maximum Start Amps A 602.8 628.9 616.7
Recommended Mains Fuse Size A 400 400 355
Evaporator
Immersion Heater Rating W 170 170 170
Condenser Fan - Per Fan (EC)
Quantity 10 9 10
Full Load Amps A 3.9 3.9 3.9
Motor Rating kW 2.6 2.6 2.6
Compressor - Per Compressor
Nominal Run Amps A 59.2 / 55.2 47.9 / 55.2 47.9 / 47.9
Quantity 2 + 3 3 + 3 3 + 3
Motor Rating kW 36.2 / 33.1 29.8 / 33.1 29.8 / 29.8
Sump Heater Rating W 140 140 140
Start Amps (2) A 298 / 326 326 / 326 326 / 326
OPTIONAL EXTRAS
Power Factor Correction (PF 0.98) (3)
Nominal Run Amps A 316.2 339.5 326.1
Reactive power reduction/saving (4) kVAr 41.1 39.7 28.5
Maximum Start Amps A 579.6 606.9 601.7
Recommended Mains Fuse Size A 400 400 355
Electronic Soft-start
Nominal Run Amps A 339.4 361.5 341.1
Maximum Start Amps A 472.4 498.5 486.3
Recommended Mains Fuse A 400 400 355
Power Factor Correction (PF
0.98) & Electronic Soft Start (3)
Nominal Run Amps A 316.2 339.5 326.1
Maximum Start Amps A 449.2 476.5 471.3
Recommended Mains Fuse Size A 400.0 400.0 355.0
Standard Head Pump (Single
or Run/Standby)
Pump Full Load Amps A 21.2 21.2 21.2
Unit Nominal Run Amps A 360.5 382.5 362.1
Recommended Mains Fuse Size A 400 400 400
Motor Rating kW 12.1 12.1 12.1
Larger Head Pump (Single
or Run/Standby)
Pump Full Load Amps A 28.5 28.5 28.5
Unit Nominal Run Amps A 367.8 389.8 369.3
Recommended Mains Fuse Size A 400 450 400
Motor Rating kW 16.4 16.4 16.4
Standard Head Inverter Pump
(Single or Run/Standby)
Pump Full Load Amps A 19.8 19.8 19.8
Unit Nominal Run Amps A 355.3 377.5 357.4
Recommended Mains Fuse Size A 400 400 400
Motor Rating kW 12.4 12.4 12.4
Larger Head Inverter Pump
(Single or Run/Standby)
Pump Full Load Amps A 26.9 26.9 26.9
Unit Nominal Run Amps A 361.0 383.3 363.3
Recommended Mains Fuse Size A 400 450 400
Motor Rating kW 16.8 16.8 16.8
(1) Based upon 7.2°C Evap / 54.4°C Condensing, AC Fans.
(2) Starting amps refers to the direct online connections.
(3) For unit RLA values at alternative power factor values contact Airedale.
(4) Projected reactive power reduction based on a 0.95PF billing threshold.
DCF Electrical Data - Regular Quiet
