AIREDALE DeltaChill - Page 109

Technic al
Chillers
DeltaChill™ Air Cooled and FreeCool
109
Chiller Technical Manual 7267818 V1.13.0_01_2018
FreeCool
ELECTRICAL DATA 10 11 12
Unit Data DCF058DR-10DVV0 DCF062DR-10FVW0 DCF065DR-10FWW0
Nominal Run Amps (1) A 390.0 402.0 414.1
Maximum Start Amps A 657.4 665.4 649.5
Recommended Mains Fuse Size A 450 450 450
Evaporator
Immersion Heater Rating W 170 170 170
Condenser Fan - Per Fan (EC)
Quantity 10 10 10
Full Load Amps A 3.9 3.9 3.9
Motor Rating kW 2.6 2.6 2.6
Compressor - Per Compressor
Nominal Run Amps A 55.2 / 55.2 55.2 / 59.2 59.2 / 59.2
Quantity 3 + 3 3 + 3 3 + 3
Motor Rating kW 33.1 / 33.1 33.1 / 36.2 36.2 / 36.2
Sump Heater Rating W 140 140 140
Start Amps (2) A 326 / 326 326 / 298 298 / 298
OPTIONAL EXTRAS
Power Factor Correction (PF 0.98) (3)
Nominal Run Amps A 360.7 374.4 388.0
Reactive power reduction/saving (4) kVAr 50.9 48.9 46.8
Maximum Start Amps A 628.1 637.8 623.4
Recommended Mains Fuse Size A 450 450 450
Electronic Soft-start
Nominal Run Amps A 390.0 402.0 414.1
Maximum Start Amps A 527.0 535.0 530.3
Recommended Mains Fuse A 450 450 450
Power Factor Correction (PF
0.98) & Electronic Soft Start (3)
Nominal Run Amps A 360.7 374.4 388.0
Maximum Start Amps A 497.7 507.4 504.2
Recommended Mains Fuse Size A 450.0 450.0 450.0
Standard Head Pump (Single
or Run/Standby)
Pump Full Load Amps A 21.2 21.2 28.5
Unit Nominal Run Amps A 411.1 423.1 442.5
Recommended Mains Fuse Size A 450 450 500
Motor Rating kW 12.1 12.1 16.4
Larger Head Pump (Single
or Run/Standby)
Pump Full Load Amps A 28.5 28.5 35.0
Unit Nominal Run Amps A 418.4 430.4 448.9
Recommended Mains Fuse Size A 450 450 500
Motor Rating kW 16.4 16.4 20.3
Standard Head Inverter Pump
(Single or Run/Standby)
Pump Full Load Amps A 19.8 19.8 26.9
Unit Nominal Run Amps A 405.7 417.9 435.8
Recommended Mains Fuse Size A 450 450 500
Motor Rating kW 12.4 12.4 16.8
Larger Head Inverter Pump
(Single or Run/Standby)
Pump Full Load Amps A 26.9 26.9 33.2
Unit Nominal Run Amps A 411.4 423.6 440.9
Recommended Mains Fuse Size A 450 450 500
Motor Rating kW 16.8 16.8 20.7
(1) Based upon 7.2°C Evap / 54.4°C Condensing, AC Fans.
(2) Starting amps refers to the direct online connections.
(3) For unit RLA values at alternative power factor values contact Airedale.
(4) Projected reactive power reduction based on a 0.95PF billing threshold.
DCF Electrical Data - Regular Quiet
