AIREDALE DeltaChill - Page 115

Technic al
Chillers
DeltaChill™ Air Cooled and FreeCool
115
Chiller Technical Manual 7267818 V1.13.0_01_2018
FreeCool
ELECTRICAL DATA 28 29 30
Unit Data DCF073TR-13GPPY DCF078TR-14GPYY DCF082TR-13HYYV
Nominal Run Amps (1) A 451.7 481.7 528.1
Maximum Start Amps A 715.1 745.1 795.5
Recommended Mains Fuse Size A 500 500 560
Evaporator
Immersion Heater Rating W 250 250 250
Condenser Fan - Per Fan (EC)
Quantity 13 14 13
Full Load Amps A 3.9 3.9 3.9
Motor Rating kW 2.6 2.6 2.6
Compressor - Per Compressor
Nominal Run Amps A 59.2 / 59.2 / 47.9 59.2 / 47.9 / 47.9 47.9 / 47.9 / 55.2
Quantity 2 + 2 + 3 2 + 3 + 3 3 + 3 + 3
Motor Rating kW 36.2 / 36.2 / 29.8 36.2 / 29.8 / 29.8 29.8 / 29.8 / 33.1
Sump Heater Rating W 140 140 140
Start Amps (2) A 298 / 298 / 326 298 / 326 / 326 326 / 326 / 326
OPTIONAL EXTRAS
Power Factor Correction (PF 0.98) (3)
Nominal Run Amps A 426.9 458.0 498.6
Reactive power reduction/saving (4) kVAr 45.5 44.1 53.9
Maximum Start Amps A 690.3 721.4 766.0
Recommended Mains Fuse Size A 500 500 560
Electronic Soft-start
Nominal Run Amps A 451.7 481.7 528.1
Maximum Start Amps A 584.7 614.7 665.1
Recommended Mains Fuse A 500 500 560
Power Factor Correction (PF
0.98) & Electronic Soft Start (3)
Nominal Run Amps A 426.9 458.0 498.6
Maximum Start Amps A 559.9 591.0 635.6
Recommended Mains Fuse Size A 500.0 500.0 560.0
Standard Head Pump (Single
or Run/Standby)
Pump Full Load Amps A 21.2 28.5 28.5
Unit Nominal Run Amps A 472.7 509.9 556.4
Recommended Mains Fuse Size A 500 560 630
Motor Rating kW 12.1 16.4 16.4
Larger Head Pump (Single
or Run/Standby)
Pump Full Load Amps A 28.5 35.0 35.0
Unit Nominal Run Amps A 480.0 516.4 562.9
Recommended Mains Fuse Size A 500 560 630
Motor Rating kW 16.4 20.3 20.3
Standard Head Inverter Pump
(Single or Run/Standby)
Pump Full Load Amps A 19.8 26.9 26.9
Unit Nominal Run Amps A 467.8 503.7 550.0
Recommended Mains Fuse Size A 500 560 630
Motor Rating kW 12.4 16.8 16.8
Larger Head Inverter Pump
(Single or Run/Standby)
Pump Full Load Amps A 26.9 33.2 33.2
Unit Nominal Run Amps A 473.6 508.8 555.1
Recommended Mains Fuse Size A 500 560 630
Motor Rating kW 16.8 20.7 20.7
(1) Based upon 7.2°C Evap / 54.4°C Condensing, AC Fans.
(2) Starting amps refers to the direct online connections.
(3) For unit RLA values at alternative power factor values contact Airedale.
(4) Projected reactive power reduction based on a 0.95PF billing threshold.
DCF Electrical Data - Regular Quiet
