AIREDALE DeltaChill - Page 116

Chillers
DeltaChill™ Air Cooled and FreeCool
116
Chiller Technical Manual 7267818 V1.13.0_01_2018
Technic al FreeCool
ELECTRICAL DATA 31 32 33
Unit Data DCF085TR-14HYVV DCF075TR-16GPPY DCF082TR-15GYYY
Nominal Run Amps (1) A 556.4 463.3 511.7
Maximum Start Amps A 823.8 726.7 787.3
Recommended Mains Fuse Size A 630 500 560
Evaporator
Immersion Heater Rating W 250 250 250
Condenser Fan - Per Fan (EC)
Quantity 14 16 15
Full Load Amps A 3.9 3.9 3.9
Motor Rating kW 2.6 2.6 2.6
Compressor - Per Compressor
Nominal Run Amps A 47.9 / 55.2 / 55.2 59.2 / 59.2 / 47.9 47.9 / 47.9 / 47.9
Quantity 3 + 3 + 3 2 + 2 + 3 3 + 3 + 3
Motor Rating kW 29.8 / 33.1 / 33.1 36.2 / 36.2 / 29.8 29.8 / 29.8 / 29.8
Sump Heater Rating W 140 140 140
Start Amps (2) A 326 / 326 / 326 298 / 298 / 326 326 / 326 / 326
OPTIONAL EXTRAS
Power Factor Correction (PF 0.98) (3)
Nominal Run Amps A 519.8 438.6 489.1
Reactive power reduction/saving (4) kVAr 65.2 45.6 42.8
Maximum Start Amps A 787.2 702.0 764.7
Recommended Mains Fuse Size A 630 500 560
Electronic Soft-start
Nominal Run Amps A 556.4 463.3 511.7
Maximum Start Amps A 693.4 596.3 656.9
Recommended Mains Fuse A 630 500 560
Power Factor Correction (PF
0.98) & Electronic Soft Start (3)
Nominal Run Amps A 519.8 438.6 489.1
Maximum Start Amps A 656.8 571.6 634.3
Recommended Mains Fuse Size A 630.0 500.0 560.0
Standard Head Pump (Single
or Run/Standby)
Pump Full Load Amps A 28.5 21.2 28.5
Unit Nominal Run Amps A 584.8 484.3 539.9
Recommended Mains Fuse Size A 630 560 560
Motor Rating kW 16.4 12.1 16.4
Larger Head Pump (Single
or Run/Standby)
Pump Full Load Amps A 35.0 28.5 35.0
Unit Nominal Run Amps A 591.3 491.6 546.4
Recommended Mains Fuse Size A 630 560 560
Motor Rating kW 20.3 16.4 20.3
Standard Head Inverter Pump
(Single or Run/Standby)
Pump Full Load Amps A 26.9 19.8 26.9
Unit Nominal Run Amps A 578.0 479.5 533.8
Recommended Mains Fuse Size A 630 500 560
Motor Rating kW 16.8 12.4 16.8
Larger Head Inverter Pump
(Single or Run/Standby)
Pump Full Load Amps A 33.2 26.9 33.2
Unit Nominal Run Amps A 583.1 485.2 539.0
Recommended Mains Fuse Size A 630 560 560
Motor Rating kW 20.7 16.8 20.7
(1) Based upon 7.2°C Evap / 54.4°C Condensing, AC Fans.
(2) Starting amps refers to the direct online connections.
(3) For unit RLA values at alternative power factor values contact Airedale.
(4) Projected reactive power reduction based on a 0.95PF billing threshold.
DCF Electrical Data - Regular Quiet
