AIREDALE DeltaChill - Page 121

Technic al
Chillers
DeltaChill™ Air Cooled and FreeCool
121
Chiller Technical Manual 7267818 V1.13.0_01_2018
FreeCool
ELECTRICAL DATA 46 47 48
Unit Data DCF088TR-19HYYV DCF090TR-20HYVV DCF095TR-21HVVV
Nominal Run Amps (1) A 551.3 579.6 608.0
Maximum Start Amps A 818.7 847.0 875.4
Recommended Mains Fuse Size A 630 630 630
Evaporator
Immersion Heater Rating W 250 250 250
Condenser Fan - Per Fan (EC)
Quantity 19 20 21
Full Load Amps A 3.9 3.9 3.9
Motor Rating kW 2.6 2.6 2.6
Compressor - Per Compressor
Nominal Run Amps A 47.9 / 47.9 / 55.2 47.9 / 55.2 / 55.2 55.2 / 55.2 / 55.2
Quantity 3 + 3 + 3 3 + 3 + 3 3 + 3 + 3
Motor Rating kW 29.8 / 29.8 / 33.1 29.8 / 33.1 / 33.1 33.1 / 33.1 / 33.1
Sump Heater Rating W 140 140 140
Start Amps (2) A 326 / 326 / 326 326 / 326 / 326 326 / 326 / 326
OPTIONAL EXTRAS
Power Factor Correction (PF 0.98) (3)
Nominal Run Amps A 522.0 543.2 564.4
Reactive power reduction/saving (4) kVAr 54.1 65.3 76.6
Maximum Start Amps A 789.4 810.6 831.8
Recommended Mains Fuse Size A 630 630 630
Electronic Soft-start
Nominal Run Amps A 551.3 579.6 608.0
Maximum Start Amps A 688.3 716.6 745.0
Recommended Mains Fuse A 630 630 630
Power Factor Correction (PF
0.98) & Electronic Soft Start (3)
Nominal Run Amps A 522.0 543.2 564.4
Maximum Start Amps A 659.0 680.2 701.4
Recommended Mains Fuse Size A 630.0 630.0 630.0
Standard Head Pump (Single
or Run/Standby)
Pump Full Load Amps A 28.5 28.5 28.5
Unit Nominal Run Amps A 579.6 607.9 636.4
Recommended Mains Fuse Size A 630 630 670
Motor Rating kW 16.4 16.4 16.4
Larger Head Pump (Single
or Run/Standby)
Pump Full Load Amps A 35.0 35.0 35.0
Unit Nominal Run Amps A 586.1 614.4 642.9
Recommended Mains Fuse Size A 630 670 670
Motor Rating kW 20.3 20.3 20.3
Standard Head Inverter Pump
(Single or Run/Standby)
Pump Full Load Amps A 26.9 26.9 26.9
Unit Nominal Run Amps A 573.2 601.2 629.5
Recommended Mains Fuse Size A 630 630 670
Motor Rating kW 16.8 16.8 16.8
Larger Head Inverter Pump
(Single or Run/Standby)
Pump Full Load Amps A 33.2 33.2 33.2
Unit Nominal Run Amps A 578.4 606.3 634.5
Recommended Mains Fuse Size A 630 630 670
Motor Rating kW 20.7 20.7 20.7
(1) Based upon 7.2°C Evap / 54.4°C Condensing, AC Fans.
(2) Starting amps refers to the direct online connections.
(3) For unit RLA values at alternative power factor values contact Airedale.
(4) Projected reactive power reduction based on a 0.95PF billing threshold.
DCF Electrical Data - Regular Quiet
