AIREDALE DeltaChill - Page 122

Chillers
DeltaChill™ Air Cooled and FreeCool
122
Chiller Technical Manual 7267818 V1.13.0_01_2018
Technic al FreeCool
ELECTRICAL DATA 49 50 51
Unit Data DCF098TR-21HVVW DCF101TR-21HVWW DCF103TR-21HWWW
Nominal Run Amps (1) A 620.1 632.2 644.4
Maximum Start Amps A 883.5 895.6 879.8
Recommended Mains Fuse Size A 670 670 670
Evaporator
Immersion Heater Rating W 250 250 250
Condenser Fan - Per Fan (EC)
Quantity 21 21 21
Full Load Amps A 3.9 3.9 3.9
Motor Rating kW 2.6 2.6 2.6
Compressor - Per Compressor
Nominal Run Amps A 55.2 / 55.2 / 59.2 55.2 / 59.2 / 59.2 59.2 / 59.2 / 59.2
Quantity 3 + 3 + 3 3 + 3 + 3 3 + 3 + 3
Motor Rating kW 33.1 / 33.1 / 36.2 33.1 / 36.2 / 36.2 36.2 / 36.2 / 36.2
Sump Heater Rating W 140 140 140
Start Amps (2) A 326 / 326 / 298 326 / 298 / 298 298 / 298 / 298
OPTIONAL EXTRAS
Power Factor Correction (PF 0.98) (3)
Nominal Run Amps A 578.0 591.7 605.4
Reactive power reduction/saving (4) kVAr 74.5 72.4 70.3
Maximum Start Amps A 841.4 855.1 840.8
Recommended Mains Fuse Size A 670 670 670
Electronic Soft-start
Nominal Run Amps A 620.1 632.2 644.4
Maximum Start Amps A 753.1 765.2 760.6
Recommended Mains Fuse A 670 670 670
Power Factor Correction (PF
0.98) & Electronic Soft Start (3)
Nominal Run Amps A 578.0 591.7 605.4
Maximum Start Amps A 711.0 724.7 721.6
Recommended Mains Fuse Size A 670.0 670.0 670.0
Standard Head Pump (Single
or Run/Standby)
Pump Full Load Amps A 28.5 35.0 35.0
Unit Nominal Run Amps A 648.4 667.0 679.1
Recommended Mains Fuse Size A 670 710 710
Motor Rating kW 16.4 20.3 20.3
Larger Head Pump (Single
or Run/Standby)
Pump Full Load Amps A 35.0 41.5 41.5
Unit Nominal Run Amps A 654.9 673.5 685.6
Recommended Mains Fuse Size A 710 710 710
Motor Rating kW 20.3 23.9 23.9
Standard Head Inverter Pump
(Single or Run/Standby)
Pump Full Load Amps A 26.9 33.2 33.2
Unit Nominal Run Amps A 641.6 658.9 671.2
Recommended Mains Fuse Size A 670 710 710
Motor Rating kW 16.8 20.7 20.7
Larger Head Inverter Pump
(Single or Run/Standby)
Pump Full Load Amps A 33.2 39.2 39.2
Unit Nominal Run Amps A 646.7 663.7 676.0
Recommended Mains Fuse Size A 710 710 710
Motor Rating kW 20.7 24.4 24.4
(1) Based upon 7.2°C Evap / 54.4°C Condensing, AC Fans.
(2) Starting amps refers to the direct online connections.
(3) For unit RLA values at alternative power factor values contact Airedale.
(4) Projected reactive power reduction based on a 0.95PF billing threshold.
DCF Electrical Data - Regular Quiet
