AIREDALE DeltaChill - Page 125

Technic al
Chillers
DeltaChill™ Air Cooled and FreeCool
125
Chiller Technical Manual 7267818 V1.13.0_01_2018
FreeCool
ELECTRICAL DATA 58 59 60
Unit Data DCF053DX-12DPV0 DCF055DX-11DYV0 DCF055DX-12DYY0
Nominal Run Amps (1) A 347.1 369.2 348.9
Maximum Start Amps A 610.5 636.6 624.5
Recommended Mains Fuse Size A 400 400 400
Evaporator
Immersion Heater Rating W 170 170 170
Condenser Fan - Per Fan (EC)
Quantity 12 11 12
Full Load Amps A 3.9 3.9 3.9
Motor Rating kW 2.6 2.6 2.6
Compressor - Per Compressor
Nominal Run Amps A 59.2 / 55.2 47.9 / 55.2 47.9 / 47.9
Quantity 2 + 3 3 + 3 3 + 3
Motor Rating kW 36.2 / 33.1 29.8 / 33.1 29.8 / 29.8
Sump Heater Rating W 140 140 140
Start Amps (2) A 298 / 326 326 / 326 326 / 326
OPTIONAL EXTRAS
Power Factor Correction (PF 0.98) (3)
Nominal Run Amps A 324.0 347.3 333.8
Reactive power reduction/saving (4) kVAr 41.2 39.8 28.6
Maximum Start Amps A 587.4 614.7 609.4
Recommended Mains Fuse Size A 400 400 400
Electronic Soft-start
Nominal Run Amps A 347.1 369.2 348.9
Maximum Start Amps A 480.1 506.2 494.1
Recommended Mains Fuse A 400 400 400
Power Factor Correction (PF
0.98) & Electronic Soft Start (3)
Nominal Run Amps A 324.0 347.3 333.8
Maximum Start Amps A 457.0 484.3 479.0
Recommended Mains Fuse Size A 400 400 400
Standard Head Pump (Single
or Run/Standby)
Pump Full Load Amps A 14.8 21.2 14.8
Unit Nominal Run Amps A 361.8 390.2 363.5
Recommended Mains Fuse Size A 400 450 400
Motor Rating kW 8.4 12.1 8.4
Larger Head Pump (Single
or Run/Standby)
Pump Full Load Amps A 21.2 28.5 21.2
Unit Nominal Run Amps A 368.2 397.5 369.8
Recommended Mains Fuse Size A 400 450 400
Motor Rating kW 12.1 16.4 12.1
Standard Head Inverter Pump
(Single or Run/Standby)
Pump Full Load Amps A 13.9 19.8 13.9
Unit Nominal Run Amps A 358.2 385.3 360.3
Recommended Mains Fuse Size A 400 450 400
Motor Rating kW 8.6 12.4 8.6
Larger Head Inverter Pump
(Single or Run/Standby)
Pump Full Load Amps A 19.8 26.9 19.8
Unit Nominal Run Amps A 363.1 391.0 365.2
Recommended Mains Fuse Size A 400 450 400
Motor Rating kW 12.4 16.8 12.4
(1) Based upon 7.2°C Evap / 54.4°C Condensing, AC Fans.
(2) Starting amps refers to the direct online connections.
(3) For unit RLA values at alternative power factor values contact Airedale.
(4) Projected reactive power reduction based on a 0.95PF billing threshold.
DCF Electrical Data Extra Quiet
