AIREDALE DeltaChill - Page 136

Chillers
DeltaChill™ Air Cooled and FreeCool
136
Chiller Technical Manual 7267818 V1.13.0_01_2018
Technic al FreeCool
ELECTRICAL DATA 91 92 93
Unit Data DCF088TX-20HYVV DCF084TX-21GYYY DCF087TX-22HYYV
Nominal Run Amps (1) A 579.6 535.0 562.9
Maximum Start Amps A 847.0 810.6 830.3
Recommended Mains Fuse Size A 630 560 630
Evaporator
Immersion Heater Rating W 250 250 250
Condenser Fan - Per Fan (EC)
Quantity 20 21 22
Full Load Amps A 3.9 3.9 3.9
Motor Rating kW 2.6 2.6 2.6
Compressor - Per Compressor
Nominal Run Amps A 47.9 / 55.2 / 55.2 47.9 / 47.9 / 47.9 47.9 / 47.9 / 55.2
Quantity 3 + 3 + 3 3 + 3 + 3 3 + 3 + 3
Motor Rating kW 29.8 / 33.1 / 33.1 29.8 / 29.8 / 29.8 29.8 / 29.8 / 33.1
Sump Heater Rating W 140 140 140
Start Amps (2) A 326 / 326 / 326 326 / 326 / 326 326 / 326 / 326
OPTIONAL EXTRAS
Power Factor Correction (PF 0.98) (3)
Nominal Run Amps A 543.2 512.4 533.6
Reactive power reduction/saving (4) kVAr 65.3 42.9 54.1
Maximum Start Amps A 810.6 788.0 801.0
Recommended Mains Fuse Size A 630 560 630
Electronic Soft-start
Nominal Run Amps A 579.6 535.0 562.9
Maximum Start Amps A 716.6 680.2 699.9
Recommended Mains Fuse A 630 560 630
Power Factor Correction (PF
0.98) & Electronic Soft Start (3)
Nominal Run Amps A 543.2 512.4 533.6
Maximum Start Amps A 680.2 657.6 670.6
Recommended Mains Fuse Size A 630 560 630
Standard Head Pump (Single
or Run/Standby)
Pump Full Load Amps A 28.5 28.5 28.5
Unit Nominal Run Amps A 607.9 563.2 591.2
Recommended Mains Fuse Size A 630 630 630
Motor Rating kW 16.4 16.4 16.4
Larger Head Pump (Single
or Run/Standby)
Pump Full Load Amps A 35.0 35.0 35.0
Unit Nominal Run Amps A 614.4 569.6 597.7
Recommended Mains Fuse Size A 670 630 630
Motor Rating kW 20.3 20.3 20.3
Standard Head Inverter Pump
(Single or Run/Standby)
Pump Full Load Amps A 26.9 26.9 26.9
Unit Nominal Run Amps A 601.2 557.1 584.9
Recommended Mains Fuse Size A 630 630 630
Motor Rating kW 16.8 16.8 16.8
Larger Head Inverter Pump
(Single or Run/Standby)
Pump Full Load Amps A 33.2 33.2 33.2
Unit Nominal Run Amps A 606.3 562.3 590.0
Recommended Mains Fuse Size A 630 630 630
Motor Rating kW 20.7 20.7 20.7
(1) Based upon 7.2°C Evap / 54.4°C Condensing, AC Fans.
(2) Starting amps refers to the direct online connections.
(3) For unit RLA values at alternative power factor values contact Airedale.
(4) Projected reactive power reduction based on a 0.95PF billing threshold.
DCF Electrical Data Extra Quiet
