Ambient (°C)
Model
Supply
Temp
°C
25°C 30°C 35°C 40°C
Output Input Output Input Output Input Output Input
kW kW kW kW kW kW kW kW
141
DCC093TR-21GVWW
5 953.4 240.7 908.5 265.9 857.6 294.6 802.0 327.1
6 982.0 242.4 936.1 267.6 884.0 296.3 827.3 329.0
7 1011.0 244.2 964.1 269.3 910.8 298.1 852.4 330.6
8 1040.3 245.9 991.5 270.9 938.0 299.8 878.3 332.4
9 1070.0 247.7 1020.3 272.7 965.6 301.7 904.8 334.4
10 1099.9 249.6 1050.1 274.7 993.6 303.5 931.3 336.2
142
DCC096TR-21GWWW
5 986.4 252.2 940.2 278.5 887.6 308.3 830.9 342.4
6 1015.7 254.0 968.5 280.3 914.6 310.2 856.5 344.2
7 1045.3 255.8 997.1 282.1 942.1 312.0 882.5 346.1
8 1075.2 257.7 1024.7 283.6 969.9 313.9 909.0 348.1
9 1105.6 259.6 1054.1 285.6 998.2 315.9 935.9 350.0
10 1136.0 261.5 1085.0 287.8 1026.8 317.9 963.2 352.0
143
DCC048DX-10EPV0
5 496.4 131.9 469.2 145.9 439.4 161.7 407.0 179.5
6 510.5 132.9 482.7 146.9 452.0 162.8 418.8 180.6
7 524.8 133.9 496.3 147.9 464.8 163.8 430.7 181.7
8 539.2 134.9 510.0 148.9 477.8 164.9 442.8 182.8
9 553.7 136.0 523.9 150.0 490.8 166.0 455.0 183.9
10 568.3 137.0 537.8 151.1 504.1 167.2 467.4 185.1
144
DCC049DX-10EYY0
5 517.5 143.7 489.4 158.5 458.6 175.3 425.3 193.9
6 532.1 144.8 503.2 159.7 471.6 176.5 437.3 195.1
7 546.8 145.9 517.2 160.8 484.7 177.7 449.6 196.4
8 561.7 147.0 531.4 162.0 498.0 178.9 462.0 197.6
9 576.7 148.2 545.6 163.2 511.5 180.2 474.6 198.9
10 591.8 149.4 560.0 164.5 525.1 181.4 487.3 200.2
145
DCC049DX-12EPV0
5 508.7 127.3 482.4 140.5 453.3 155.7 421.6 172.9
6 523.5 128.1 496.6 141.4 466.7 156.6 434.1 173.8
7 538.4 129.0 510.8 142.2 480.2 157.5 446.8 174.7
8 553.4 129.8 525.3 143.1 493.9 158.4 459.6 175.6
9 568.5 130.7 539.8 144.0 507.8 159.3 472.7 176.5
10 583.7 131.6 554.5 144.9 521.7 160.2 485.9 177.5
146
DCC051DX-12EYY0
5 530.4 138.4 503.3 152.6 473.3 168.7 440.6 186.7
6 545.6 139.3 517.8 153.5 487.0 169.7 453.5 187.7
7 561.0 140.3 532.5 154.5 500.9 170.7 466.5 188.7
8 576.5 141.2 547.4 155.5 515.0 171.7 479.7 189.8
9 592.2 142.2 562.4 156.5 529.2 172.7 493.1 190.8
10 607.9 143.2 577.5 157.5 543.6 173.8 506.7 191.9
147
DCC053DX-11DYV0
5 551.7 146.6 521.5 161.9 488.4 179.2 452.5 198.6
6 567.5 147.7 536.5 163.0 502.4 180.4 465.6 199.8
7 583.5 148.8 551.7 164.1 516.7 181.6 478.9 201.0
8 599.6 150.0 567.0 165.3 531.1 182.8 492.3 202.2
9
615.9 151.1 582.5 166.5 545.7 184.0 506.0 203.5
10 632.3 152.4 598.1 167.8 560.5 185.3 519.8 204.8
1 Output kW refers to the chilled water duty.
2 Input kW refers to the unit input power (compressor + fans).
3 Duties applicable for chilled water ∆T between 4 and 8°C.
4 Interpolate for water temperatures between those quoted, do not extrapolate.
5 Water ow rate (l/s) = Output ÷ (Cp x ∆T)
6 For conditions outside of those quoted please refer to Airedale.
DCC Performance Data EC Fans
