Ambient (°C)
Model
Supply
Temp
°C
25°C 30°C 35°C 40°C
Output Input Output Input Output Input Output Input
kW kW kW kW kW kW kW kW
162
DCC065DX-16DWW0
5 670.4 164.2 635.6 181.1 597.3 200.4 555.7 222.2
6 689.8 165.3 654.1 182.1 614.8 201.5 572.0 223.4
7 709.3 166.4 672.8 183.3 632.5 202.6 588.6 224.5
8 729.1 167.6 691.8 184.4 650.4 203.8 605.4 225.7
9 749.1 168.7 710.9 185.6 668.6 205.0 622.5 226.9
10 769.2 169.9 730.2 186.8 686.9 206.2 639.7 228.2
163
DCC068TX-16GPPY
5 714.8 180.2 676.8 198.6 635.1 219.7 590.1 243.4
6 735.6 181.4 696.6 199.9 653.7 221.0 607.4 244.7
7 756.6 182.7 716.5 201.2 672.6 222.3 625.0 246.1
8 777.9 184.0 736.8 202.5 691.7 223.7 642.8 247.5
9 799.3 185.4 757.3 203.9 711.0 225.1 660.9 248.9
10 821.0 186.8 777.9 205.3 730.6 226.5 679.3 250.4
164
DCC075TX-15GYYY
5 790.1 216.6 745.9 238.8 697.8 263.9 646.2 291.7
6 812.7 218.3 767.3 240.6 717.8 265.7 664.6 293.5
7 835.6 220.0 788.9 242.4 738.0 267.5 683.4 295.4
8 858.8 221.8 810.8 244.2 758.5 269.4 702.4 297.3
9 882.2 223.6 832.9 246.1 779.3 271.4 721.7 299.3
10 905.8 225.5 855.2 248.0 800.3 273.3 741.3 301.3
165
DCC077TX-16GYYV
5 812.6 218.6 767.6 241.3 718.4 267.0 665.4 295.6
6 836.1 220.3 789.8 243.0 739.2 268.7 684.6 297.4
7 859.8 222.0 812.2 244.8 760.2 270.5 704.2 299.2
8 883.7 223.7 834.9 246.6 781.5 272.4 724.0 301.1
9 907.9 225.5 857.9 248.4 803.1 274.3 744.1 303.0
10 932.4 227.4 881.1 250.3 825.0 276.2 764.5 305.0
166
DCC072TX-17GPYY
5 752.2 193.7 712.9 213.6 669.7 236.2 622.9 261.5
6 774.0 195.0 733.7 214.9 689.3 237.6 641.2 262.9
7 796.0 196.4 754.7 216.3 709.1 239.0 659.7 264.4
8 818.3 197.7 776.0 217.7 729.2 240.4 678.5 265.9
9 840.8 199.2 797.5 219.1 749.6 241.9 697.6 267.4
10 863.5 200.6 819.2 220.6 770.2 243.4 716.9 268.9
167
DCC077TX-18GYYY
5 810.9 208.5 768.0 229.7 721.0 253.8 670.2 280.8
6 834.6 210.0 790.5 231.2 742.2 255.3 689.9 282.3
7 858.6 211.5 813.3 232.7 763.6 256.9 709.9 283.9
8 882.9 213.0 836.4 234.3 785.4 258.5 730.3 285.5
9 907.4 214.5 859.8 235.9 807.5 260.1 750.9 287.2
10 932.2 216.1 883.4 237.5 829.8 261.8 771.9 288.8
168
DCC080TX-17GYVV
5 835.1 220.7 789.3 243.8 739.0 270.1 684.7 299.5
6 859.4 222.3 812.3 245.4 760.6 271.8 704.7 301.3
7 883.9 224.0 835.6 247.1 782.4 273.5 725.0 303.0
8 908.7 225.7 859.1 248.9 804.6 275.3 745.6 304.9
9
933.7 227.4 882.9 250.7 827.0 277.2 766.5 306.7
10 959.0 229.3 906.9 252.6 849.7 279.1 787.7 308.7
1 Output kW refers to the chilled water duty.
2 Input kW refers to the unit input power (compressor + fans).
3 Duties applicable for chilled water ∆T between 4 and 8°C.
4 Interpolate for water temperatures between those quoted, do not extrapolate.
5 Water ow rate (l/s) = Output ÷ (Cp x ∆T)
6 For conditions outside of those quoted please refer to Airedale.
DCC Performance Data EC Fans
