Ambient (°C)
Model
Supply
Temp
°C
25°C 30°C 35°C 40°C
Output Input Output Input Output Input Output Input
kW kW kW kW kW kW kW kW
169
DCC083TX-18GVVV
5 857.7 222.7 811.0 246.2 759.6 273.2 703.9 303.4
6 882.7 224.3 834.8 247.9 782.0 274.8 724.7 305.1
7 908.1 225.9 858.9 249.5 804.7 276.5 745.8 306.8
8 933.7 227.6 883.2 251.2 827.6 278.3 767.2 308.6
9 959.5 229.3 907.9 253.0 850.9 280.1 789.0 310.5
10 985.6 231.1 932.7 254.8 874.4 281.9 811.0 312.3
170
DCC086TX-18GVVW
5 895.4 235.5 845.4 260.2 790.7 288.4 731.8 320.1
6 921.5 237.2 870.1 262.0 813.9 290.3 753.2 322.0
7 947.9 239.1 895.1 263.9 837.3 292.2 774.9 324.0
8 974.6 240.9 920.4 265.8 861.0 294.2 797.0 325.9
9 1001.5 242.9 945.9 267.8 885.1 296.2 819.4 328.0
10 1028.8 244.9 971.8 269.8 909.4 298.3 842.1 330.1
171
DCC088TX-18GVWW
5 924.8 247.7 872.9 273.7 816.2 303.3 755.1 336.4
6 951.4 249.6 898.0 275.6 839.7 305.3 776.8 338.5
7 978.2 251.5 923.4 277.7 863.5 307.4 798.9 340.6
8 1005.3 253.6 949.1 279.7 887.5 309.5 821.2 342.8
9 1032.7 255.6 975.0 281.9 911.9 311.7 843.9 345.1
10 1060.3 257.8 1001.2 284.1 936.5 314.0 866.9 347.3
172
DCC091TX-18GWWW
5 954.3 259.9 900.4 287.1 841.7 318.1 778.4 352.8
6 981.3 261.9 925.9 289.3 865.5 320.3 800.4 355.0
7 1008.5 264.0 951.7 291.5 889.6 322.6 822.8 357.3
8 1036.0 266.2 977.8 293.7 914.1 324.9 845.5 359.7
9 1063.8 268.4 1004.1 296.0 938.8 327.2 868.5 362.1
10 1091.7 270.7 1030.6 298.3 963.7 329.7 891.7 364.6
173
DCC070TX-19GPPY
5 728.6 175.6 691.9 193.4 651.1 213.7 606.7 236.7
6 750.3 176.7 712.4 194.4 670.5 214.8 624.9 237.8
7 772.2 177.9 733.2 195.6 690.2 215.9 643.3 239.0
8 794.2 179.0 754.3 196.7 710.1 217.1 662.1 240.2
9 816.4 180.2 775.6 197.9 730.4 218.3 681.1 241.4
10 838.9 181.4 797.1 199.1 750.8 219.5 700.4 242.6
174
DCC074TX-20GPYY
5 765.7 189.0 727.7 208.2 685.4 230.0 639.3 254.7
6 788.3 190.2 749.2 209.3 705.8 231.2 658.4 255.9
7 811.2 191.4 771.0 210.5 726.4 232.4 677.8 257.1
8 834.2 192.6 793.1 211.7 747.4 233.7 697.5 258.4
9 857.4 193.8 815.4 213.0 768.6 234.9 717.5 259.7
10 880.8 195.1 837.9 214.3 790.1 236.2 737.7 261.0
175
DCC079TX-21GYYY
5 825.5 203.6 783.6 224.1 737.4 247.4 687.4 273.7
6 849.9 204.9 806.9 225.3 759.5 248.7 708.0 275.0
7 874.7 206.2 830.5 226.7 781.8 250.1 728.9 276.4
8 899.8 207.5 854.5 228.0 804.5 251.4 750.2 277.8
9
925.2 208.9 878.8 229.4 827.5 252.9 771.8 279.2
10 950.8 210.3 903.3 230.8 850.8 254.3 793.7 280.7
1 Output kW refers to the chilled water duty.
2 Input kW refers to the unit input power (compressor + fans).
3 Duties applicable for chilled water ∆T between 4 and 8°C.
4 Interpolate for water temperatures between those quoted, do not extrapolate.
5 Water ow rate (l/s) = Output ÷ (Cp x ∆T)
6 For conditions outside of those quoted please refer to Airedale.
DCC Performance Data EC Fans
