Ambient (°C)
Model
Supply
Temp
°C
25°C 30°C 35°C 40°C
Output Input Output Input Output Input Output Input
kW kW kW kW kW kW kW kW
176
DCC080TX-19GYYV
5 832.1 211.2 788.3 232.9 740.2 257.6 688.1 285.4
6 856.5 212.7 811.5 234.3 762.1 259.1 708.5 286.9
7 881.2 214.1 835.1 235.8 784.3 260.6 729.2 288.4
8 906.2 215.6 859.0 237.4 806.8 262.2 750.3 290.0
9 931.5 217.2 883.1 238.9 829.7 263.8 771.7 291.6
10 957.1 218.8 907.5 240.5 852.7 265.4 793.3 293.3
177
DCC081TX-22GYYV
5 845.5 206.6 803.1 227.6 755.9 251.6 704.5 278.7
6 870.7 207.9 827.2 228.8 778.6 252.9 725.8 280.0
7 896.3 209.2 851.5 230.1 801.7 254.2 747.4 281.3
8 922.2 210.5 876.2 231.5 825.1 255.5 769.3 282.7
9 948.3 211.9 901.1 232.9 848.8 256.9 791.6 284.1
10 974.6 213.4 926.4 234.3 872.8 258.4 814.2 285.5
178
DCC082TX-20GYVV
5 853.2 213.9 808.6 236.0 759.4 261.4 706.0 290.0
6 878.4 215.3 832.6 237.5 782.1 262.8 727.1 291.5
7 903.9 216.8 856.9 238.9 805.0 264.3 748.5 293.0
8 929.6 218.3 881.5 240.4 828.3 265.9 770.3 294.5
9 955.6 219.8 906.4 242.0 851.8 267.4 792.4 296.1
10 981.9 221.4 931.5 243.6 875.7 269.1 814.8 297.7
179
DCC085TX-21GVVV
5 874.4 216.7 828.9 239.2 778.7 265.2 723.9 294.6
6 900.3 218.0 853.7 240.6 802.0 266.6 745.7 296.0
7 926.5 219.4 878.7 242.0 825.7 268.1 767.9 297.5
8 953.0 220.9 904.1 243.5 849.7 269.6 790.4 299.0
9 979.8 222.4 929.7 245.0 874.0 271.1 813.2 300.6
10 1006.7 224.0 955.6 246.6 898.6 272.7 836.3 302.2
180
DCC088TX-21GVVW
5 914.3 228.5 865.5 252.2 811.9 279.5 753.9 310.2
6 941.4 230.1 891.3 253.8 836.2 281.1 776.4 311.8
7 968.8 231.7 917.4 255.4 860.8 282.7 799.3 313.5
8 996.5 233.3 943.8 257.1 885.7 284.4 822.6 315.2
9 1024.5 235.0 970.1 258.8 910.9 286.1 846.2 317.0
10 1052.8 236.7 997.5 260.5 936.5 287.9 870.2 318.8
181
DCC091TX-21GVWW
5 945.2 239.9 894.6 264.8 839.0 293.4 778.8 325.5
6 972.7 241.6 920.8 266.5 863.7 295.1 801.8 327.3
7 1000.6 243.3 947.3 268.3 888.7 296.9 825.1 329.1
8 1028.8 245.0 974.2 270.0 914.0 298.7 848.7 331.0
9 1057.3 246.9 1000.6 272.0 939.6 300.6 872.7 332.9
10 1086.0 248.7 1028.8 273.8 965.6 302.5 897.0 334.9
182
DCC094TX-21GWWW
5 976.0 251.3 923.6 277.4 866.1 307.3 803.8 340.8
6 1004.1 253.1 950.3 279.2 891.2 309.1 827.1 342.8
7 1032.5 254.9 977.3 281.1 916.6 311.1 850.8 344.8
8 1061.2 256.8 1004.6 283.0 942.3 313.0 874.8 346.8
9
1090.1 258.7 1031.1 285.2 968.4 315.1 899.2 348.8
10 1119.2 260.7 1060.0 287.0 994.7 317.1 923.9 351.0
1 Output kW refers to the chilled water duty.
2 Input kW refers to the unit input power (compressor + fans).
3 Duties applicable for chilled water ∆T between 4 and 8°C.
4 Interpolate for water temperatures between those quoted, do not extrapolate.
5 Water ow rate (l/s) = Output ÷ (Cp x ∆T)
6 For conditions outside of those quoted please refer to Airedale.
DCC Performance Data EC Fans
