AIREDALE DeltaChill - Page 205

Technic al
Chillers
DeltaChill™ Air Cooled and FreeCool
205
Chiller Technical Manual 7267818 V1.13.0_01_2018
Air Cooled
ELECTRICAL DATA 155 156 157
Unit Data DCC060DX-14DVW0 DCC063DX-14DWW0 DCC066TX-13GPPY
Nominal Run Amps (1) A 417.4 429.6 451.7
Maximum Start Amps A 680.8 665.0 715.1
Recommended Mains Fuse Size A 450 450 500
Evaporator
Immersion Heater Rating W 170 170 250
Condenser Fan - Per Fan (EC)
Quantity 14 14 13
Full Load Amps A 3.9 3.9 3.9
Motor Rating kW 2.6 2.6 2.6
Compressor - Per Compressor
Nominal Run Amps A 55.2 / 59.2 59.2 / 59.2 59.2 / 59.2 / 47.9
Quantity 3 + 3 3 + 3 2 + 2 + 3
Motor Rating kW 33.1 / 36.2 36.2 / 36.2 36.2 / 36.2 / 29.8
Sump Heater Rating W 140 140 140
Start Amps (2) A 326 / 298 298 / 298 298 / 298 / 326
OPTIONAL EXTRAS
Power Factor Correction (PF 0.98) (3)
Nominal Run Amps A 389.9 403.6 426.9
Reactive power reduction/saving (4) kVAr 49.0 46.9 45.5
Maximum Start Amps A 653.3 639.0 690.3
Recommended Mains Fuse Size A 450 450 500
Electronic Soft-start
Nominal Run Amps A 417.4 429.6 451.7
Maximum Start Amps A 550.4 545.8 584.7
Recommended Mains Fuse A 450 450 500
Power Factor Correction (PF
0.98) & Electronic Soft Start (3)
Nominal Run Amps A 389.9 403.6 426.9
Maximum Start Amps A 522.9 519.8 559.9
Recommended Mains Fuse Size A 450 450 500
Standard Head Pump (Single
or Run/Standby)
Pump Full Load Amps A 11.2 11.2 11.2
Unit Nominal Run Amps A 428.5 440.6 462.7
Recommended Mains Fuse Size A 450 500 500
Motor Rating kW 6.2 6.2 6.2
Larger Head Pump (Single
or Run/Standby)
Pump Full Load Amps A 14.8 14.8 21.2
Unit Nominal Run Amps A 432.1 444.2 472.7
Recommended Mains Fuse Size A 450 500 500
Motor Rating kW 8.4 8.4 12.1
Standard Head Inverter Pump
(Single or Run/Standby)
Pump Full Load Amps A 10.2 10.2 10.2
Unit Nominal Run Amps A 425.6 437.8 460.0
Recommended Mains Fuse Size A 450 500 500
Motor Rating kW 6.4 6.4 6.4
Larger Head Inverter Pump
(Single or Run/Standby)
Pump Full Load Amps A 13.9 13.9 19.8
Unit Nominal Run Amps A 428.5 440.7 467.8
Recommended Mains Fuse Size A 450 500 500
Motor Rating kW 8.6 8.6 12.4
(1) Based at 7.2°C Evap / 54.4°C Condensing, AC Standard Fans.
(2) Starting amps refers to the direct on line connections.
(3) For unit RLA values at alternative power factor values contact Airedale.
(4) Projected reactive power reduction based on a 0.95PF billing threshold
DCC Electrical Data - Extra Quiet
