AIREDALE DeltaChill - Page 206

Technic al
Chillers
DeltaChill™ Air Cooled and FreeCool
206
Chiller Technical Manual 7267818 V1.13.0_01_2018
Air Cooled
ELECTRICAL DATA 158 159 160
Unit Data DCC070TX-14GPYY DCC055DX-15DYV0 DCC059DX-16DVV0
Nominal Run Amps (1) A 481.7 384.7 413.0
Maximum Start Amps A 745.1 652.1 680.4
Recommended Mains Fuse Size A 500 450 450
Evaporator
Immersion Heater Rating W 250 170 170
Condenser Fan - Per Fan (EC)
Quantity 14 15 16
Full Load Amps A 3.9 3.9 3.9
Motor Rating kW 2.6 2.6 2.6
Compressor - Per Compressor
Nominal Run Amps A 59.2 / 47.9 / 47.9 47.9 / 55.2 55.2 / 55.2
Quantity 2 + 3 + 3 3 + 3 3 + 3
Motor Rating kW 36.2 / 29.8 / 29.8 29.8 / 33.1 33.1 / 33.1
Sump Heater Rating W 140 140 140
Start Amps (2) A 298 / 326 / 326 326 / 326 326 / 326
OPTIONAL EXTRAS
Power Factor Correction (PF 0.98) (3)
Nominal Run Amps A 458.0 362.8 384.0
Reactive power reduction/saving (4) kVAr 44.1 39.8 51.1
Maximum Start Amps A 721.4 630.2 651.4
Recommended Mains Fuse Size A 500 450 450
Electronic Soft-start
Nominal Run Amps A 481.7 384.7 413.0
Maximum Start Amps A 614.7 521.7 550.0
Recommended Mains Fuse A 500 450 450
Power Factor Correction (PF
0.98) & Electronic Soft Start (3)
Nominal Run Amps A 458.0 362.8 384.0
Maximum Start Amps A 591.0 499.8 521.0
Recommended Mains Fuse Size A 500 450 450
Standard Head Pump (Single
or Run/Standby)
Pump Full Load Amps A 11.2 8.9 11.2
Unit Nominal Run Amps A 492.7 393.1 424.1
Recommended Mains Fuse Size A 560 450 450
Motor Rating kW 6.2 4.4 6.2
Larger Head Pump (Single
or Run/Standby)
Pump Full Load Amps A 21.2 11.2 11.2
Unit Nominal Run Amps A 502.6 395.7 424.1
Recommended Mains Fuse Size A 560 450 450
Motor Rating kW 12.1 6.1 6.1
Standard Head Inverter Pump
(Single or Run/Standby)
Pump Full Load Amps A 10.2 7.3 10.2
Unit Nominal Run Amps A 490.0 390.5 421.2
Recommended Mains Fuse Size A 560 450 450
Motor Rating kW 6.4 4.5 6.4
Larger Head Inverter Pump
(Single or Run/Standby)
Pump Full Load Amps A 19.8 10.1 10.1
Unit Nominal Run Amps A 497.9 392.8 421.1
Recommended Mains Fuse Size A 560 450 450
Motor Rating kW 12.4 6.3 6.3
(1) Based at 7.2°C Evap / 54.4°C Condensing, AC Standard Fans.
(2) Starting amps refers to the direct on line connections.
(3) For unit RLA values at alternative power factor values contact Airedale.
(4) Projected reactive power reduction based on a 0.95PF billing threshold
DCC Electrical Data - Extra Quiet
