AIREDALE DeltaChill - Page 211

Technic al
Chillers
DeltaChill™ Air Cooled and FreeCool
211
Chiller Technical Manual 7267818 V1.13.0_01_2018
Air Cooled
ELECTRICAL DATA 173 174 175
Unit Data DCC070TX-19GPPY DCC074TX-20GPYY DCC080TX-19GYYV
Nominal Run Amps (1) A 474.9 504.9 535.0
Maximum Start Amps A 738.3 768.3 810.6
Recommended Mains Fuse Size A 500 560 560
Evaporator
Immersion Heater Rating W 250 250 250
Condenser Fan - Per Fan (EC)
Quantity 19 20 21
Full Load Amps A 3.9 3.9 3.9
Motor Rating kW 2.6 2.6 2.6
Compressor - Per Compressor
Nominal Run Amps A 59.2 / 59.2 / 47.9 59.2 / 47.9 / 47.9 47.9 / 47.9 / 47.9
Quantity 2 + 2 + 3 2 + 3 + 3 3 + 3 + 3
Motor Rating kW 36.2 / 36.2 / 29.8 36.2 / 29.8 / 29.8 29.8 / 29.8 / 29.8
Sump Heater Rating W 140 140 140
Start Amps (2) A 298 / 298 / 326 298 / 326 / 326 326 / 326 / 326
OPTIONAL EXTRAS
Power Factor Correction (PF 0.98) (3)
Nominal Run Amps A 450.2 481.3 512.4
Reactive power reduction/saving (4) kVAr 45.6 44.3 42.9
Maximum Start Amps A 713.6 744.7 788.0
Recommended Mains Fuse Size A 500 560 560
Electronic Soft-start
Nominal Run Amps A 474.9 504.9 535.0
Maximum Start Amps A 607.9 637.9 680.2
Recommended Mains Fuse A 500 560 560
Power Factor Correction (PF
0.98) & Electronic Soft Start (3)
Nominal Run Amps A 450.2 481.3 512.4
Maximum Start Amps A 583.2 614.3 657.6
Recommended Mains Fuse Size A 500 560 560
Standard Head Pump (Single
or Run/Standby)
Pump Full Load Amps A 11.2 11.2 11.2
Unit Nominal Run Amps A 485.9 515.9 545.9
Recommended Mains Fuse Size A 560 560 560
Motor Rating kW 6.2 6.2 6.2
Larger Head Pump (Single
or Run/Standby)
Pump Full Load Amps A 21.2 21.2 21.2
Unit Nominal Run Amps A 495.9 525.9 555.9
Recommended Mains Fuse Size A 560 560 630
Motor Rating kW 12.1 12.1 12.1
Standard Head Inverter Pump
(Single or Run/Standby)
Pump Full Load Amps A 10.2 10.2 10.2
Unit Nominal Run Amps A 483.2 513.3 543.4
Recommended Mains Fuse Size A 560 560 560
Motor Rating kW 6.4 6.4 6.4
Larger Head Inverter Pump
(Single or Run/Standby)
Pump Full Load Amps A 19.8 19.8 19.8
Unit Nominal Run Amps A 491.1 521.2 551.3
Recommended Mains Fuse Size A 560 560 630
Motor Rating kW 12.4 12.4 12.4
(1) Based at 7.2°C Evap / 54.4°C Condensing, AC Standard Fans.
(2) Starting amps refers to the direct on line connections.
(3) For unit RLA values at alternative power factor values contact Airedale.
(4) Projected reactive power reduction based on a 0.95PF billing threshold
DCC Electrical Data - Extra Quiet
