AIREDALE DeltaChill - Page 210

Technic al
Chillers
DeltaChill™ Air Cooled and FreeCool
210
Chiller Technical Manual 7267818 V1.13.0_01_2018
Air Cooled
ELECTRICAL DATA 170 171 172
Unit Data DCC086TX-18GVVW DCC088TX-18GVWW DCC091TX-18GWWW
Nominal Run Amps (1) A 608.5 620.6 632.8
Maximum Start Amps A 871.9 884.0 868.2
Recommended Mains Fuse Size A 630 670 670
Evaporator
Immersion Heater Rating W 250 250 250
Condenser Fan - Per Fan (EC)
Quantity 18 18 18
Full Load Amps A 3.9 3.9 3.9
Motor Rating kW 2.6 2.6 2.6
Compressor - Per Compressor
Nominal Run Amps A 55.2 / 55.2 / 59.2 55.2 / 59.2 / 59.2 59.2 / 59.2 / 59.2
Quantity 3 + 3 + 3 3 + 3 + 3 3 + 3 + 3
Motor Rating kW 33.1 / 33.1 / 36.2 33.1 / 36.2 / 36.2 36.2 / 36.2 / 36.2
Sump Heater Rating W 140 140 140
Start Amps (2) A 326 / 326 / 298 326 / 298 / 298 298 / 298 / 298
OPTIONAL EXTRAS
Power Factor Correction (PF 0.98) (3)
Nominal Run Amps A 566.4 580.1 593.7
Reactive power reduction/saving (4) kVAr 74.4 72.3 70.3
Maximum Start Amps A 829.8 843.5 829.1
Recommended Mains Fuse Size A 630 670 670
Electronic Soft-start
Nominal Run Amps A 608.5 620.6 632.8
Maximum Start Amps A 741.5 753.6 749.0
Recommended Mains Fuse A 630 670 670
Power Factor Correction (PF
0.98) & Electronic Soft Start (3)
Nominal Run Amps A 566.4 580.1 593.7
Maximum Start Amps A 699.4 713.1 709.9
Recommended Mains Fuse Size A 630 670 670
Standard Head Pump (Single
or Run/Standby)
Pump Full Load Amps A 11.2 11.2 15.2
Unit Nominal Run Amps A 619.6 631.7 647.7
Recommended Mains Fuse Size A 670 670 670
Motor Rating kW 6.2 6.2 8.4
Larger Head Pump (Single
or Run/Standby)
Pump Full Load Amps A 21.2 21.2 21.2
Unit Nominal Run Amps A 629.6 641.7 653.8
Recommended Mains Fuse Size A 670 670 710
Motor Rating kW 12.1 12.1 12.1
Standard Head Inverter Pump
(Single or Run/Standby)
Pump Full Load Amps A 10.2 10.2 13.9
Unit Nominal Run Amps A 616.7 628.8 643.9
Recommended Mains Fuse Size A 670 670 670
Motor Rating kW 6.4 6.4 8.6
Larger Head Inverter Pump
(Single or Run/Standby)
Pump Full Load Amps A 19.8 19.8 19.8
Unit Nominal Run Amps A 624.4 636.5 648.7
Recommended Mains Fuse Size A 670 670 670
Motor Rating kW 12.4 12.4 12.4
(1) Based at 7.2°C Evap / 54.4°C Condensing, AC Standard Fans.
(2) Starting amps refers to the direct on line connections.
(3) For unit RLA values at alternative power factor values contact Airedale.
(4) Projected reactive power reduction based on a 0.95PF billing threshold
DCC Electrical Data - Extra Quiet
