DeltaChill™ Air Cooled and FreeCool
DCC Units with 100% Water
Waterow(l/s)
Unit
4 6 8 10 12 14 16 18 20 22 24 26 28 30 32 34 36 38 40 42 44 46 48 50
Pressure Drop (kPa)
125 DCC061DR-14DVW0 2.2 3.8 5.7 7.8 10.3 13.1 16.2 19.5 23.2 27.2 31.5 36.1 41.0 46.1 51.6 57.4 63.5 69.9 76.5 83.5 90.8 98.4 106.3 114.5
126 DCC065DR-14DWW0 3.0 5.2 7.9 11.0 14.7 18.8 23.3 28.4 33.9 39.8 46.3 53.2 60.6 68.4 76.7 85.5 94.8 104.5 114.7 125.4 136.5 148.1 160.2 172.7
127 DCC068TR-13GPPY 2.2 3.8 5.6 7.8 10.2 13.0 16.1 19.4 23.1 27.1 31.3 35.9 40.8 46.0 51.4 57.2 63.3 69.6 76.3 83.3 90.5 98.1 106.0 114.1
128 DCC072TR-14GPYY 1.3 2.3 3.4 4.7 6.2 7.8 9.7 11.7 13.9 16.3 18.9 21.7 24.6 27.7 31.0 34.5 38.2 42.0 46.0 50.2 54.6 59.2 63.9 68.9
129 DCC077TR-13GYYV 1.5 2.6 3.8 5.2 6.8 8.6 10.6 12.7 15.1 17.6 20.3 23.2 26.3 29.6 33.0 36.7 40.5 44.5 48.7 53.1 57.6 62.4 67.3 72.4
130 DCC080TR-14GYVV 1.5 2.6 3.8 5.2 6.8 8.6 10.6 12.7 15.1 17.6 20.3 23.2 26.3 29.6 33.0 36.7 40.5 44.5 48.7 53.1 57.6 62.4 67.3 72.4
131 DCC050DX-14EPV0 2.8 5.0 7.9 11.3 15.2 19.8 24.9 30.6 36.8 43.6 51.0 59.0 67.6 76.7 86.3 96.6 107.4 118.8 130.8 143.3 156.4 170.1 184.3 199.1
132 DCC052DX-14EYY0 2.8 5.0 7.9 11.3 15.2 19.8 24.9 30.6 36.8 43.6 51.0 59.0 67.6 76.7 86.3 96.6 107.4 118.8 130.8 143.3 156.4 170.1 184.3 199.1
133 DCC054DX-13DYV0 1.9 3.3 5.0 6.9 9.2 11.7 14.5 17.6 20.9 24.6 28.5 32.7 37.2 42.0 47.0 52.3 58.0 63.9 70.0 76.5 83.2 90.2 97.5 105.1
134 DCC057DX-14DVV0 2.9 5.0 7.5 10.4 13.8 17.5 21.6 26.1 31.1 36.4 42.2 48.3 54.9 61.9 69.2 77.0 85.2 93.8 102.8 112.2 122.0 132.2 142.9 153.9
135 DCC060DX-14DVW0 2.2 3.8 5.7 7.8 10.3 13.1 16.2 19.5 23.2 27.2 31.5 36.1 41.0 46.1 51.6 57.4 63.5 69.9 76.5 83.5 90.8 98.4 106.3 114.5
136 DCC063DX-14DWW0 3.0 5.2 7.9 11.0 14.7 18.8 23.3 28.4 33.9 39.8 46.3 53.2 60.6 68.4 76.7 85.5 94.8 104.5 114.7 125.4 136.5 148.1 160.2 172.7
137 DCC066TX-13GPPY 2.2 3.8 5.6 7.8 10.2 13.0 16.1 19.4 23.1 27.1 31.3 35.9 40.8 46.0 51.4 57.2 63.3 69.6 76.3 83.3 90.5 98.1 106.0 114.1
138 DCC070TX-14GPYY 1.3 2.3 3.4 4.7 6.2 7.8 9.7 11.7 13.9 16.3 18.9 21.7 24.6 27.7 31.0 34.5 38.2 42.0 46.0 50.2 54.6 59.2 63.9 68.9
139 DCC070TR-16GPPY 2.2 3.8 5.6 7.8 10.3 13.0 16.1
19.5 23.1 27.1 31.4 35.9 40.8 46.0 51.4 57.2 63.3 69.7 76.3 83.3 90.6 98.1 106.0 114.2
140 DCC077TR-15GYYY 1.5 2.6 3.8 5.3 6.9 8.7 10.7 12.9 15.3 17.8 20.6 23.5 26.7 30.0 33.5 37.2 41.1 45.1 49.4 53.8 58.5 63.3 68.3 73.5
141 DCC080TR-16GYYV 1.5 2.6 3.8 5.3 6.9 8.7 10.7 12.9 15.3 17.8 20.6 23.5 26.7 30.0 33.5 37.2 41.1 45.1 49.4 53.8 58.5 63.3 68.3 73.5
142 DCC083TR-15GVVV 1.5 2.6 3.8 5.3 6.9 8.7 10.7 12.9 15.3 17.8 20.6 23.5 26.7 30.0 33.5 37.2 41.1 45.1 49.4 53.8 58.5 63.3 68.3 73.5
143 DCC086TR-15GVVW 1.0 1.6 2.4 3.3 4.3 5.5 6.7 8.1 9.5 11.1 12.8 14.7 16.6 18.7 20.8 23.1 25.5 28.0 30.7 33.4 36.3 39.2 42.3 45.5
144 DCC088TR-15GVWW 1.0 1.6 2.4 3.3 4.3 5.5 6.7 8.1 9.5 11.1 12.8 14.7 16.6 18.7 20.8 23.1 25.5 28.0 30.7 33.4 36.3 39.2 42.3 45.5
145
DCC091TR-
15GWWW 1.0 1.6 2.4 3.3 4.3 5.5 6.7 8.1 9.5 11.1 12.8 14.7 16.6 18.7 20.8 23.1 25.5 28.0 30.7 33.4 36.3 39.2 42.3 45.5
146 DCC055DX-15DYV0 1.9 3.3 5.0 6.9 9.2 11.7 14.5 17.6 20.9 24.6 28.5 32.7 37.2 42.0 47.0 52.4 58.0 63.9 70.1 76.5 83.3 90.3 97.6 105.2
147 DCC059DX-16DVV0 2.9 5.0 7.5 10.4 13.8 17.5 21.6 26.1 31.1 36.4 42.2 48.3 54.9 61.9 69.3 77.1 85.2 93.8 102.8 112.3 122.1 132.3 142.9 154.0
148 DCC061DX-16DVW0 2.2 3.8 5.7 7.8 10.3 13.1 16.2 19.6 23.2 27.2 31.5 36.1 41.0 46.2 51.6 57.4 63.5 69.9 76.6 83.6 90.9 98.5 106.3 114.5
149 DCC065DX-16DWW0 3.0 5.2 7.9 11.0 14.7 18.8 23.3 28.4 33.9 39.9 46.3 53.2 60.6 68.5 76.8 85.6 94.8 104.6 114.8 125.4 136.6 148.2 160.3 172.8
150 DCC068TX-16GPPY 2.2 3.8 5.6 7.8 10.3 13.0 16.1 19.5 23.1 27.1 31.4 35.9 40.8 46.0 51.4 57.2 63.3 69.7 76.3 83.3 90.6 98.1 106.0 114.2
151 DCC075TX-15GYYY 1.6 2.7 3.9 5.4 7.1 9.0 11.1 13.4 15.9 18.5 21.4 24.5 27.8 31.3 34.9 38.8 42.9 47.2 51.6 56.3 61.1 66.2 71.5 76.9
DCC Unit Pressure Drop
