Chiller Technical Manual 7267818 V1.11.0_09_2016
DeltaChill™ Air Cooled and FreeCool
Chillers
Waterow(l/s)
Unit
4 6 8 10 12 14 16 18 20 22 24 26 28 30 32 34 36 38 40 42 44 46 48 50
Pressure Drop (kPa)
152 DCC077TX-16GYYV 1.6 2.7 3.9 5.4 7.1 9.0 11.1 13.4 15.9 18.5 21.4 24.5 27.8 31.3 34.9 38.8 42.9 47.2 51.6 56.3 61.1 66.2 71.5 76.9
153 DCC074TR-17GPYY 1.3 2.2 3.3 4.5 5.9 7.5 9.3 11.2 13.3 15.6 18.0 20.7 23.4 26.4 29.5 32.8 36.3 39.9 43.7 47.7 51.8 56.2 60.6 65.3
154 DCC079TR-18GYYY 1.5 2.6 3.8 5.3 6.9 8.7 10.7 12.9 15.2 17.8 20.5 23.5 26.6 29.9 33.4 37.1 41.0 45.0 49.3 53.7 58.3 63.1 68.1 73.3
155 DCC082TR-17GYVV 1.5 2.6 3.8 5.3 6.9 8.7 10.7 12.9 15.2 17.8 20.5 23.5 26.6 29.9 33.4 37.1 41.0 45.0 49.3 53.7 58.3 63.1 68.1 73.3
156 DCC085TR-18GVVV 1.5 2.6 3.8 5.3 6.9 8.7 10.7 12.9 15.2 17.8 20.5 23.5 26.6 29.9 33.4 37.1 41.0 45.0 49.3 53.7 58.3 63.1 68.1 73.3
157 DCC088TR-18GVVW 1.0 1.6 2.4 3.3 4.3 5.4 6.7 8.0 9.5 11.1 12.8 14.6 16.5 18.6 20.7 23.0 25.4 27.9 30.5 33.2 36.1 39.1 42.1 45.3
158 DCC091TR-18GVWW 1.0 1.6 2.4 3.3 4.3 5.4 6.7 8.0 9.5 11.1 12.8 14.6 16.5 18.6 20.7 23.0 25.4 27.9 30.5 33.2 36.1 39.1 42.1 45.3
159
DCC094TR-
18GWWW 1.0 1.6 2.4 3.3 4.3 5.4 6.7 8.0 9.5 11.1 12.8 14.6 16.5 18.6 20.7 23.0 25.4 27.9 30.5 33.2 36.1 39.1 42.1 45.3
160 DCC072TX-17GPYY 1.3 2.2 3.3 4.5 5.9 7.5 9.3 11.2 13.3 15.6 18.0 20.7 23.4 26.4 29.5 32.8 36.3 39.9 43.7 47.7 51.8 56.2 60.6 65.3
161 DCC077TX-18GYYY 1.5 2.6 3.8 5.3 6.9 8.7 10.7 12.9 15.2 17.8 20.5 23.5 26.6 29.9 33.4 37.1 41.0 45.0 49.3 53.7 58.3 63.1 68.1 73.3
162 DCC080TX-17GYVV 1.5 2.6 3.8 5.3 6.9 8.7 10.7 12.9 15.2 17.8 20.5 23.5 26.6 29.9 33.4 37.1 41.0 45.0 49.3 53.7 58.3 63.1 68.1 73.3
163 DCC083TX-18GVVV 1.5 2.6 3.8 5.3 6.9 8.7 10.7 12.9 15.2 17.8 20.5 23.5 26.6 29.9 33.4 37.1 41.0 45.0 49.3 53.7 58.3 63.1 68.1 73.3
164 DCC086TX-18GVVW 1.0 1.6 2.4 3.3 4.3 5.4 6.7 8.0 9.5 11.1 12.8 14.6 16.5 18.6 20.7 23.0 25.4 27.9 30.5 33.2 36.1 39.1 42.1 45.3
165 DCC088TX-18GVWW 1.0 1.6 2.4 3.3 4.3 5.4 6.7 8.0 9.5 11.1 12.8 14.6 16.5 18.6 20.7 23.0 25.4 27.9 30.5 33.2 36.1 39.1 42.1 45.3
166
DCC091TX-
18GWWW 1.0 1.6 2.4 3.3 4.3
5.4 6.7 8.0 9.5 11.1 12.8 14.6 16.5 18.6 20.7 23.0 25.4 27.9 30.5 33.2 36.1 39.1 42.1 45.3
167 DCC082TR-19GYYV 1.5 2.6 3.9 5.3 6.9 8.8 10.8 13.0 15.4 18.0 20.8 23.7 26.9 30.2 33.8 37.5 41.4 45.5 49.8 54.3 59.0 63.9 68.9 74.2
168 DCC084TR-20GYVV 1.5 2.6 3.9 5.3 6.9 8.8 10.8 13.0 15.4 18.0 20.8 23.7 26.9 30.2 33.8 37.5 41.4 45.5 49.8 54.3 59.0 63.9 68.9 74.2
169 DCC087TR-21GVVV 1.5 2.6 3.9 5.3 7.0 8.8 10.9 13.1 15.6 18.2 21.0 24.0 27.2 30.6 34.2 37.9 41.9 46.1 50.4 55.0 59.7 64.6 69.7 75.1
170 DCC090TR-21GVVW 1.0 1.7 2.5 3.4 4.4 5.6 6.9 8.3 9.8 11.5 13.2 15.1 17.1 19.2 21.5 23.9 26.3 28.9 31.7 34.5 37.5 40.5 43.7 47.1
171 DCC093TR-21GVWW 1.0 1.7 2.5 3.4 4.4 5.6 6.9 8.3 9.8 11.5 13.2 15.1 17.1 19.2 21.5 23.9 26.3 28.9 31.7 34.5 37.5 40.5 43.7 47.1
172
DCC096TR-
21GWWW 1.0 1.7 2.5 3.4 4.4 5.6 6.9 8.3 9.8 11.5 13.2 15.1 17.1 19.2 21.5 23.9 26.3 28.9 31.7 34.5 37.5 40.5 43.7 47.1
173 DCC070TX-19GPPY 2.2 3.7 5.5 7.7 10.1 12.8 15.8 19.1 22.7 26.5 30.7 35.2 39.9 45.0 50.3 55.9 61.8 68.1 74.6 81.3 88.4 95.8 103.5 111.4
174 DCC074TX-20GPYY 1.3 2.2 3.3 4.6 6.0 7.6 9.4 11.3 13.5 15.8 18.3 20.9 23.7 26.7 29.9 33.2 36.8 40.4 44.3 48.3 52.5 56.9 61.5 66.2
175 DCC079TX-21GYYY 1.5 2.6 3.9 5.3 7.0 8.8 10.9 13.1 15.6 18.2 21.0 24.0 27.2 30.6 34.2 37.9 41.9 46.1 50.4 55.0 59.7 64.6 69.7 75.1
176 DCC080TX-19GYYV 1.5 2.6 3.9 5.3 6.9 8.8 10.8 13.0 15.4 18.0 20.8 23.7 26.9 30.2 33.8 37.5 41.4 45.5 49.8 54.3 59.0 63.9 68.9 74.2
177 DCC081TX-22GYYV 1.5 2.6 3.9 5.3 7.0 8.8 10.9 13.1 15.6 18.2 21.0 24.0 27.2 30.6 34.2 37.9 41.9 46.1 50.4 55.0 59.7 64.6 69.7 75.1
178 DCC082TX-20GYVV 1.5 2.6 3.9 5.3 6.9 8.8 10.8 13.0 15.4 18.0 20.8 23.7 26.9 30.2 33.8 37.5 41.4 45.5 49.8 54.3 59.0 63.9 68.9 74.2
179 DCC085TX-21GVVV 1.5 2.6 3.9 5.3 7.0 8.8 10.9 13.1 15.6 18.2 21.0 24.0 27.2 30.6 34.2 37.9 41.9 46.1 50.4 55.0 59.7 64.6 69.7 75.1
180 DCC088TX-21GVVW 1.0 1.7 2.5 3.4 4.4 5.6 6.9 8.3 9.8 11.5 13.2 15.1 17.1 19.2 21.5 23.9 26.3 28.9 31.7 34.5 37.5 40.5 43.7 47.1
181 DCC091TX-21GVWW 1.0 1.7 2.5 3.4 4.4 5.6 6.9 8.3 9.8 11.5 13.2 15.1 17.1 19.2
21.5 23.9 26.3 28.9 31.7 34.5 37.5 40.5 43.7 47.1
182
DCC094TX-
21GWWW 1.0 1.7 2.5 3.4 4.4 5.6 6.9 8.3 9.8 11.5 13.2 15.1 17.1 19.2 21.5 23.9 26.3 28.9 31.7 34.5 37.5 40.5 43.7 47.1
DCC Unit Pressure Drop
DCC Units with 100% Water
