1 Output kW refers to the chilled water duty (Based upon 20% Ethylene Glycol).
2 Input kW refers to the unit input power (compressor + fans).
3 Duties applicable for chilled water ∆T between 4 and 8°C.
4 Interpolate for water temperatures between those quoted, do not extrapolate.
5 Water ow rate (l/s) = Output ÷ (Cp x ∆T)
6 For conditions outside of those quoted please refer to Airedale.
Ambient (°C)
Model
Supply
Temp
°C
25°C 30°C 35°C 40°C
Output Input Output Input Output Input Output Input
kW kW kW kW kW kW kW kW
84 DCF089TX-18HVVV
6 884.4 230.2 834.8 254.4 780.6 281.9 722.1 312.6
7 909.7 232.0 858.7 256.2 803.0 283.7 742.9 314.5
8 935.2 233.9 882.9 258.1 825.7 285.7 764.0 316.4
10 987.2 237.8 932.1 262.1 872.0 289.7 807.1 320.5
12 1040.1 241.9 982.4 266.3 919.3 293.9 851.3 324.8
14 1093.8 246.2 1033.5 270.7 967.6 298.4 896.6 329.4
85 DCF092TX-18HVVW
6 913.0 243.0 861.4 268.5 805.2 297.4 744.6 329.7
7 938.7 245.0 885.7 270.5 827.9 299.4 765.6 331.8
8 964.6 247.0 910.2 272.6 850.9 301.6 787.0 333.9
10 1017.2 251.1 960.1 276.8 897.8 305.9 830.6 338.4
12 1070.7 255.5 1010.9 281.4 945.6 310.6 875.3 343.1
14 1124.9 260.2 1062.5 286.1 994.4 315.4 921.0 348.0
86 DCF094TX-18HVWW
6 941.6 255.8 888.1 282.6 829.9 312.9 767.0 346.8
7 967.6 257.9 912.7 284.8 852.9 315.2 788.4 349.0
8 993.9 260.0 937.6 287.0 876.2 317.5 810.0 351.4
10 1047.2 264.5 988.1 291.6 923.6 322.2 854.1 356.2
12 1101.3 269.2 1039.5 296.5 971.9 327.2 899.2 361.3
14 1156.0 274.1 1091.6 301.5 1021.2 332.4 945.5 366.7
87 DCF096TX-18HWWW
6 962.5 267.9 907.7 296.1 848.1 327.8 783.7 363.2
7 988.9 270.1 932.6 298.4 871.3 330.2 805.2 365.6
8 1015.5 272.4 957.8 300.7 894.8 332.7 827.0 368.2
10 1069.3 277.2 1008.7 305.7 942.6 337.7 871.5 373.4
12 1123.9 282.2 1060.5 310.8 991.4 343.0 917.0 378.8
14 1179.0 287.3 1113.1 316.2 1041.0 348.6 963.5 384.5
88 DCF074TX-19GPPY
6 738.6 179.8 699.8 197.9 657.6 218.5 612.1 241.8
7 760.2 181.0 720.4 199.1 677.0 219.7 630.1 243.0
8 782.0 182.2 741.2 200.3 696.6 221.0 648.5 244.3
10 826.5 184.8 783.6 202.9 736.7 223.6 686.0 246.9
12 872.0 187.5 827.0 205.6 777.9 226.3 724.7 249.7
14 918.4 190.4 871.4 208.5 820.0 229.2 764.3 252.6
89 DCF079TX-20GPYY
6 795.2 194.6 753.2 214.0 707.5 236.2 658.2 261.1
7 818.5 195.9 775.3 215.3 728.3 237.5 677.6 262.5
8 842.1 197.2 797.7 216.7 749.4 238.9 697.4 263.8
10 890.1 200.0 843.5 219.5 792.6 241.8 737.8 266.7
12 939.3 203.0 890.4 222.5 837.0 244.8 779.4 269.8
14 989.6 206.2 938.3 225.7 882.4 247.9 822.2 272.9
90 DCF085TX-19HYYV
6 843.3 216.8 798.7 239.1 749.9 264.3 696.9 292.5
7 867.3 218.4 821.6 240.6 771.4 265.9 717.0 294.1
8 891.6 219.9 844.7 242.3 793.2 267.6 737.4 295.8
10 941.0 223.2 891.8 245.6 837.7 271.0 779.1 299.3
12
991.2 226.7 939.8 249.2 883.3 274.6 821.9 303.0
14 1042.1 230.3 988.7 252.9 929.8 278.4 865.8 306.9
DCF Performance Data EC Fans
