1 Output kW refers to the chilled water duty (Based upon 20% Ethylene Glycol).
2 Input kW refers to the unit input power (compressor + fans).
3 Duties applicable for chilled water ∆T between 4 and 8°C.
4 Interpolate for water temperatures between those quoted, do not extrapolate.
5 Water ow rate (l/s) = Output ÷ (Cp x ∆T)
6 For conditions outside of those quoted please refer to Airedale.
Ambient (°C)
Model
Supply
Temp
°C
25°C 30°C 35°C 40°C
Output Input Output Input Output Input Output Input
kW kW kW kW kW kW kW kW
91 DCF088TX-20HYVV
6 864.6 219.5 819.3 242.2 769.4 268.1 715.2 297.1
7 889.4 221.0 842.9 243.7 791.7 269.6 735.9 298.7
8 914.4 222.5 866.8 245.3 814.2 271.3 757.0 300.4
10 965.2 225.8 915.3 248.6 860.2 274.7 800.2 303.8
12 1016.8 229.2 964.8 252.1 907.2 278.2 844.4 307.4
14 1069.0 232.8 1015.0 255.8 955.1 282.0 889.8 311.3
92 DCF084TX-21GYYY
6 839.4 208.6 795.5 229.5 747.6 253.3 696.0 279.8
7 863.9 210.0 818.8 230.9 769.6 254.7 716.5 281.3
8 888.8 211.5 842.4 232.4 791.9 256.2 737.3 282.8
10 939.3 214.4 890.6 235.4 837.4 259.2 779.9 285.9
12 991.1 217.6 940.0 238.6 884.1 262.4 823.8 289.1
14 1043.9 220.9 990.4 241.9 932.0 265.8 868.9 292.5
93 DCF087TX-22HYYV
6 858.6 211.6 815.1 233.1 767.2 257.5 715.1 285.0
7 883.4 213.0 838.8 234.4 789.7 258.9 736.1 286.4
8 908.5 214.4 862.8 235.8 812.4 260.3 757.5 287.8
10 959.5 217.3 911.7 238.8 858.8 263.3 801.1 290.9
12 1011.3 220.3 961.5 241.9 906.3 266.5 846.0 294.1
14 1063.9 223.6 1012.2 245.1 954.8 269.8 891.9 297.4
94 DCF092TX-21HVVV
6 904.2 223.2 855.8 246.3 802.7 272.8 745.2 302.6
7 930.4 224.8 880.8 247.9 826.3 274.4 767.2 304.2
8 957.0 226.4 906.1 249.5 850.2 276.0 789.5 305.9
10 1011.1 229.8 957.6 252.9 898.9 279.5 835.1 309.3
12 1066.3 233.4 1010.3 256.6 948.8 283.1 881.9 313.0
14 1122.4 237.2 1064.0 260.4 999.7 287.0 929.9 317.0
95 DCF095TX-21HVVW
6 934.3 235.0 884.1 259.4 829.1 287.2 769.5 318.5
7 961.0 236.7 909.5 261.1 853.1 289.0 791.8 320.3
8 988.1 238.5 935.2 262.9 877.3 290.8 814.5 322.1
10 1042.9 242.1 987.6 266.6 926.7 294.5 860.7 326.0
12 1098.8 246.0 1040.9 270.5 977.3 298.5 908.1 330.0
14 1155.5 250.0 1095.2 274.7 1028.8 302.7 956.8 334.2
96 DCF097TX-21HVWW
6 964.4 246.9 912.4 272.5 855.5 301.7 793.8 334.4
7 991.6 248.7 938.3 274.4 879.8 303.6 816.5 336.4
8 1019.1 250.6 964.4 276.3 904.4 305.6 839.4 338.4
10 1074.8 254.5 1017.5 280.3 954.5 309.6 886.3 342.6
12 1131.3 258.6 1071.5 284.5 1005.7 313.9 934.4 346.9
14 1188.5 262.9 1126.4 288.9 1057.9 318.4 983.6 351.5
97 DCF099TX-21HWWW
6 986.5 258.2 933.3 285.1 875.0 315.6 811.9 349.8
7 1014.0 260.1 959.4 287.1 899.6 317.6 834.8 351.9
8 1041.8 262.1 985.9 289.1 924.5 319.7 858.0 354.1
10 1098.2 266.2 1039.6 293.3 975.2 324.1 905.3 358.5
12
1155.3 270.5 1094.2 297.8 1026.9 328.6 953.9 363.2
14 1213.0 275.0 1149.5 302.4 1079.5 333.4 1003.5 368.1
DCF Performance Data EC Fans
