AIREDALE DeltaChill - Page 98

Chillers
DeltaChill™ Air Cooled and FreeCool
98
Chiller Technical Manual 7267818 V1.13.0_01_2018
Technic al FreeCool
76 77 78
DCF066DX-16FVW0 DCF069DX-16FWW0 DCF073TX-16GPPY
FreeCooling Yes Yes Yes
Enhance Capital Allowance No No No
Number of Refrigeration Circuits 2 2 3
Cooling Duty - EC Fans
Nominal Output - Mechanical (1) kW 645.0 675.4 715.1
Nominal Input - Mechanical kW 196.1 210.5 231.1
EER (2) 3.29 3.21 3.09
ESEER 4.32 4.24 4.11
Nominal Output - Free Cooling kW 556.3 565.5 578.7
Ambient temperature for
100% Free Cooling
(5) °C 1 0.6 0.1
Capacity Steps % 15-35-50-70-85-100 20-35-55-70-85-100 15-35-45-60-75-90-100
Minimum Turndown Ratio 0.17 0.18 0.17
Dimensions (H x W x L) mm 2682 x 2200 x 9374 2682 x 2200 x 9374 2682 x 2200 x 9374
Weight
Machine (3) kg 7125 7265 7710
Operating kg 8230 8500 9135
Water Volume (Total Internal) l 1105 1235 1425
Maximum Waterow l/s 41.9 41.9 46.1
Minimum Waterow l/s 16.0 16.0 17.7
Face Area (Total) m² 2.38 2.38 2.38
Nominal Airow - EC Fans m³/s 64.0 64.0 64.0
Quantity 16 16 16
Maximum Speed - EC Fans rpm 725 725 725
Compressor Trio + Trio Trio + Trio
Tandem +
Tandem + Trio
Quantity of Compressors 6 6 7
Oil Charge Volume (Total) l 3 x 5.3 + 3 x 5.3 3 x 5.3 + 3 x 5.3
2 x 5.3 + 2 x 5.3
+ 3 x 5.3
Refrigeration R410A / 2088
Charge (Total) kg 46 + 44 46 + 44 30 + 33 + 35
GWP Tonnes Equivalent CO
2
tCO2 96 + 92 96 + 92 63 + 69 + 73
Refrigerant Control Electronic Expansion Valve (EEV)
Water Inlet / Outlet - Unit DN125 DN150 DN150
Water Drain / Bleed - Evap inch 1/2 1/2 1/2
Water System
Minimum System Water Volume (4) l 1977 2204 2181
Maximum System
Operating Pressure
Bar 10 10 10
(1) Based on units performance at 15/10°C return/supply temperatures, 35°C ambient, 20% Ethylene Glycol.
All performance data supplied in accordance with BBS EN14511-1:2013
(2) EER = DX Cooling Output / (Compressor input power + Fan Input Power),
(3) Based on standard unit without options, operating weight includes refrigerant charge and water volume.
For unit weights with waterside options tted please refer to Airedale.
(4) For minimum system volume, refer to Design Features & Information - Minimum System Water Volume Calculations
(5) Ambient temperature that full Freecool capacity can be achieved
DCF Mechanical Data Extra Quiet
