Akai MPC 4000 User Manual

Effect mode
152
Mix page
Adjusting the effect output level
Here you can adjust the level of the signal that is output from effects 1–4. This page also
lets you specify whether the effect will also output the direct signal.
To access this page........[EFFECT] key → [F3] key (MIX)
A Effect block
Functions
• [F1] key (SELECT)
Displays the Select page.
• [F2] key (EDIT)
Displays the Edit page.
Effect block
Here you can specify the output level of the effects, and specify whether the direct signal
will be output from the effect.
A Effect field
Displays the effect type. This field also lets you can also switch the effect type.
B Out field
Selects the jack from which the output signal of the effect will be sent.
C Level field
Adjusts the output level of the effect.
D Direct signal field
Specifies whether the original signal that is being input to the effect (the direct signal)
will be output together with the processed signal (the effect sound). Turn this OFF if you
want to output only the effect sound. If this is OFF, the balance between the direct signal
and the effect sound will be specified by the Wet/Dry field in the edit page of each effect.
1
1
5
23 4
