List page
193
B Type field
Selects the type of program that will be created.
C [F1] key (CANCEL)
Cancels the operation and closes the popup window.
D [F6] key (DO IT)
Executes the Create New Program operation.
3. Move the cursor to the New name field, and turn the [JOG] dial.
The Rename popup window will appear.
4. Input the program name, and press the [F6] key (ENTER).
The name will be finalized, and the popup window will close.
5. Move the cursor to the Type field, and turn the [JOG] dial to select the type of
program.
6. To create the program, press the [F6] key (DO IT).
The popup window will close, and you will return to the List page. The newly created
program will be added to the program list.
■ Assigning a program change number to a program
Here’s how to assign a program change number to a program in memory, so that you can
use program change events to select it.
1. In the List page, move the cursor to the Program No. field of the program for
which you want to assign a program change number.
2. Turn the [JOG] dial.
The Program Number popup window will appear.
A Program field
Indicates the name of the program for which a program change number will be assigned.
B Program number field
Selects the program change number.
C [F1] key (CLOSE)
Updates the setting and closes the popup window.
3. Turn the [JOG] dial to select the desired program change number (1–128).
Select OFF if you don’t want to assign a number.
4. To update the setting, press the [F1] key.
1
3
2
