Program mode
210
The Mute Group popup window will appear.
A Mute Group field
Indicates the mute group that will be displayed in the list.
B Kg/Note field
Indicates the key groups or note numbers that are assigned to the same mute group.
C Zone 1 Sample field
Indicates the name of the sample that is assigned to zone 1 of each key group or note
number.
D [F1] key (CLOSE)
Closes the popup window.
6. To close the popup window, press the [F1] key (CLOSE).
1
2
3
4

Akai MPC 4000 Specifications

General

Polyphony	64 voices
RAM	272 MB (expandable to 512 MB)
Pads	16 velocity and pressure-sensitive pads
MIDI	2 MIDI inputs, 4 MIDI outputs
Sampling Frequency	44.1 kHz
Display	240x64 backlit LCD
Effects	4 internal effects processors
Storage	Internal Hard Drive
Sequencer	300, 000 notes capacity
Filter	Multi-mode filter (Low Pass, High Pass, Band Pass, Band Boost, Band Reject)
