Program mode
198
Key group mix page
Editing the mix parameters of a program
Here you can assign samples to a key group program or drum program, and adjust the
level, pan, and output destination for each key group or note number.
To access this page........[PROGRAM] key → [F2] key (KG MIX)
A Program block
B Sample list block
Functions
• [F1] key (LIST)
Displays the List page.
• [F3] key (PITCH)
Displays the pitch page.
• [F4] key (EDIT 1)
Displays the Edit 1 page.
• [F5] key (EDIT 2)
Displays the Edit 2 page.
• [F6] key (ZONE)
Displays the Zone page.
Program block
This area displays various information for the currently selected program.
A Tag field
A symbol will be displayed here for a program that you tagged in the List page.
B Program field
Indicates the currently selected program. When the cursor is located at this field, you can
turn the [JOG] dial to select a program.
C Type field
Indicates the type of program that is selected.
1
2
1
2
1
4
23
56
