Save page
85
Disk information block
This area shows various information about the storage device that is selected as the
save-destination.
A Device field
An icon indicates the type of device that is selected. The way in which the device is con-
nected is shown below this icon.
• INTERNAL ................ Internal ATA device
• USB............................. USB device
• SCSI0–7...................... SCSI device (the number following “SCSI” indicates the
SCSI ID)
B Type field
Indicates the format type of the storage device.
C Free field
Indicates the amount of free space on the selected storage device.
Data list block
In this area you can select the internal memory data that will be saved. The contents of
this block will depend on what you selected in the Type block.
Disk block
Here you can select the save-destination storage device.
A Disk field
Selects the save-destination storage device. When you turn the [JOG] dial in this field,
the Device List popup window will appear.
Hint: If you press the [WINDOW] key in the Disk field, the Disk Information popup window will appear.
In this popup window you can view detailed information about the storage device selected by the cursor,
such as the name of the vendor and the system version.
1
2
3
1
