Allied Telesis AT-9724TS Reference Manual

disable mirror
Purpose Used to disable a previously entered port mirroring configuration.
Syntax disable mirror
Description This command, combined with the enable mirror command above, allows you to enter a port mirroring
configuration into the Switch, and then turn the port mirroring on and off without having to modify the port
mirroring configuration
Parameters None.
Restrictions Only administrator-level users can issue this command.
Example usage:
To disable mirroring configurations:
AT-9724TS:4# disable mirror
Command: disable mirror
S u c c e s s .
A T - 9 7 2 4 T S : 4 #
show mirror
Purpose Used to show the current port mirroring configuration on the Switch.
Syntax show mirror
Description This command displays the current port mirroring configuration on the Switch.
Parameters None.
Restrictions None.
Example usage:
To display mirroring configuration:
AT-9724TS:4# show mirror
Command: show mirror
Current Settings
Mirror Status: E n a b l e d
Target Port: 9
Mirrored Port
R X :
T X : 1:1 - 1:5
A T - 9 7 2 4 T S : 4 #
102
Allied Telesyn AT-9724TS High-Density Layer 3 Stackable Gigabit Ethernet Switch • Command Line Interface Reference Manual

Allied Telesis AT-9724TS Specifications

General

MAC address table	16000 entries
Packet buffer memory	2 MB
Maximum data transfer rate	88 Gbit/s
Full duplex	Yes
Dimensions (WxDxH)	440 x 210 x 44 mm
Power requirements	100-240V AC/50-60Hz
Management platform	SNMP, RMON
Networking features	IEEE 802.3 10T Ethernet, IEEE 802.3u 100TX Ethernet, IEEE 802.3ab 1000T Ethernet, IEEE 802.3z 1000X Ethernet
Connectivity technology	Wired
DHCP features	DHCP client
Security algorithms	SSH
Switch type	Managed
Switch layer	L3+
SFP/SFP+ slots quantity	4
Basic switching RJ-45 Ethernet ports quantity	24
Memory type	SDRAM / Flash
Flash memory	16 MB
Internal memory	256 MB
Power consumption (typical)	90 W
Certification	UL 1950 FCC Class A CSA 22.2 No. 950 EN55022 Class A EN 60950 (TUV) EN50082-1 CE
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Weight	3200 g
