Page #219 background image
config vrrp ipif
Purpose To configure the authentication type for the VRRP routers of an IP interface.
Syntax config vrrp ipif <ipif_name 12> [authtype [none | simple authdata <string 8> | ip
authdata <string 16>]
Description This command is used to set the authentication type for the VRRP routers of an IP interface.
Parameters ipif <ipif_name 12> – Enter the name of a previously configured IP interface to configure the VRRP entry for.
This IP interface must be assigned to a VLAN on the Switch.
authtype – Specifies the type of authentication used.The authtype must be consistent with all routers
participating within the VRRP group.The user can choose between:
none – Entering this parameter indicates that VRRP protocol exchanges will not be authenticated.
simple authdata <string 8> This parameter, along with an alphanumeric string of no more than eight
characters, to set a simple password for comparing VRRP message packets received by a router.
If the two passwords are not exactly the same, the packet will be dropped.
ip authdata <string 16> This parameter will require the user to set an alphanumeric authentication
string of no more than 16 characters to generate a MD5 message digest for authentication in
comparing VRRP messages received by the router. If the two values are inconsistent, the packet will
be dropped.
Restrictions Only administrator-level users can issue this command.
Example usage:
To set the authentication type for a VRRP entry:
AT-9724TS:4# config vrrp ipif Trinity authtype simple
authdata tomato
Command: config vrrp ipif Trinity authtype simple authdata
t o m a t o
S u c c e s s .
A T - 9 7 2 4 T S : 4 #
show vrrp
Purpose To view the VRRP settings set on the Switch.
Syntax show vrrp ipif <ipif_name 12> vrid <vrid 1-255>
Description This command is used to view current VRRP settings of the VRRP Operations table.
Parameters ipif <ipif_name 12> – Enter the name of a previously configured IP interface to view the VRRP settings for.This
IP interface must be assigned to a VLAN on the Switch.
vrid <vrid 1-255> – Enter the VRRP ID of a VRRP entry to view these settings for.
Restrictions Only administrator-level users can issue this command.
218
Allied Telesyn AT-9724TS High-Density Layer 3 Stackable Gigabit Ethernet Switch • Command Line Interface Reference Manual
