Allied Telesis AT-9724TS Reference Manual

show arpentry
Purpose Used to display the ARP table.
Syntax show arpentry {ipif <ipif_name 12> | ipaddress <ipaddr> | static}
Description This command is used to display the current contents of the Switch’s ARP table.
Parameters <ipif_name 12> – The name of the IP interface the end node or station for which the ARP table entry was
made, resides on.
<ipaddr> – The network address corresponding to the IP interface name above.
static – Displays the static entries to the ARP table.
Restrictions None.
Example usage:
To display the ARP table:
AT-9724TS:4# show arpentry
Command: show arpentry
A R P Aging Time 30
I n t e r f a c e I P A d d r e s s M A C A d d r e s s T y p e
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
S y s t e m 1 0 . 0 . 0 . 0 F F - F F - F F - F F - F F - F F L o c a l / B r o a d c a s t
S y s t e m 1 0 . 1 . 1 . 1 6 9 0 0 - 5 0 - B A - 7 0 - E 4 - 4 E D y n a m i c
S y s t e m 1 0 . 1 . 1 . 2 5 4 0 0 - 0 1 - 3 0 - F A - 5 F - 0 0 D y n a m i c
S y s t e m 1 0 . 9 . 6 8 . 1 0 0 - A 0 - C 9 - A 4 - 2 2 - 5 B D y n a m i c
S y s t e m 1 0 . 9 . 6 8 . 4 0 0 - 8 0 - C 8 - 2 E - C 7 - 4 5 D y n a m i c
S y s t e m 1 0 . 1 0 . 2 7 . 5 1 0 0 - 8 0 - C 8 - 4 8 - D F - A B D y n a m i c
S y s t e m 1 0 . 1 1 . 2 2 . 1 4 5 0 0 - 8 0 - C 8 - 9 3 - 0 5 - 6 B D y n a m i c
S y s t e m 1 0 . 1 1 . 9 4 . 1 0 0 0 - 1 0 - 8 3 - F 9 - 3 7 - 6 E D y n a m i c
S y s t e m 1 0 . 1 4 . 8 2 . 2 4 0 0 - 5 0 - B A - 9 0 - 3 7 - 1 0 D y n a m i c
S y s t e m 1 0 . 1 5 . 1 . 6 0 0 0 - 8 0 - C 8 - 1 7 - 4 2 - 5 5 D y n a m i c
S y s t e m 1 0 . 1 7 . 4 2 . 1 5 3 0 0 - 8 0 - C 8 - 4 D - 4 E - 0 A D y n a m i c
S y s t e m 1 0 . 1 9 . 7 2 . 1 0 0 0 0 - 5 0 - B A - 3 8 - 7 D - 5 E D y n a m i c
S y s t e m 1 0 . 2 1 . 3 2 . 2 0 3 0 0 - 8 0 - C 8 - 4 0 - C 1 - 0 6 D y n a m i c
S y s t e m 1 0 . 4 0 . 4 4 . 6 0 0 0 - 5 0 - B A - 6 B - 2 A - 1 E D y n a m i c
S y s t e m 1 0 . 4 2 . 7 3 . 2 2 1 0 0 - 0 1 - 0 2 - 0 3 - 0 4 - 0 0 D y n a m i c
S y s t e m 1 0 . 4 4 . 6 7 . 1 0 0 - 5 0 - B A - D A - 0 2 - 5 1 D y n a m i c
S y s t e m 1 0 . 4 7 . 6 5 . 2 5 0 0 - 5 0 - B A - D A - 0 3 - 2 B D y n a m i c
S y s t e m 1 0 . 5 0 . 8 . 7 0 0 - E 0 - 1 8 - 4 5 - C 7 - 2 8 D y n a m i c
S y s t e m 1 0 . 9 0 . 9 0 . 9 0 0 0 - 0 1 - 0 2 - 0 3 - 0 4 - 0 0 L o c a l
S y s t e m 1 0 . 2 5 5 . 2 5 5 . 2 5 5 F F - F F - F F - F F - F F - F F L o c a l / B r o a d c a s t
Total Entries = 20
A T - 9 7 2 4 T S : 4 #
212
Allied Telesyn AT-9724TS High-Density Layer 3 Stackable Gigabit Ethernet Switch • Command Line Interface Reference Manual

Allied Telesis AT-9724TS Specifications

General

MAC address table	16000 entries
Packet buffer memory	2 MB
Maximum data transfer rate	88 Gbit/s
Full duplex	Yes
Dimensions (WxDxH)	440 x 210 x 44 mm
Power requirements	100-240V AC/50-60Hz
Management platform	SNMP, RMON
Networking features	IEEE 802.3 10T Ethernet, IEEE 802.3u 100TX Ethernet, IEEE 802.3ab 1000T Ethernet, IEEE 802.3z 1000X Ethernet
Connectivity technology	Wired
DHCP features	DHCP client
Security algorithms	SSH
Switch type	Managed
Switch layer	L3+
SFP/SFP+ slots quantity	4
Basic switching RJ-45 Ethernet ports quantity	24
Memory type	SDRAM / Flash
Flash memory	16 MB
Internal memory	256 MB
Power consumption (typical)	90 W
Certification	UL 1950 FCC Class A CSA 22.2 No. 950 EN55022 Class A EN 60950 (TUV) EN50082-1 CE
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Weight	3200 g
