Page #124 background imageLoading...
Page #124 background image
Chapter 19 - IGMP Snooping Commands
The IGMP snooping commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table.
Command Parameters
config igmp_snooping [<vlan_name 32> | all] {host_timeout <sec 1-16711450> | router_timeout <sec 1-16711450> | leave_timer
<sec 1-6711450> | state [enable | disable]}
config igmp_snooping querier [<vlan_name 32> | all] {query_interval <sec 1-65535> | max_response_time <sec 1-25> | robustness_variable
<value 1-255> | last_member_query_interval <sec 1-25> | state [enable | disable]}
enable igmp snooping {forward_mcrouter_only}
disable igmp snooping {forward_mcrouter_only}
config router_ports {vlan <vlan_name 32>} [add | delete] <portlist>
config router_ports_forbidden <vlan_name 32> [add | delete] <portlist>
show router_ports {<vlan_name 32>} {static | dynamic | forbidden}
show igmp_snooping {vlan <vlan_name 32>}
show igmp_snooping group {vlan <vlan_name 32>}
show igmp_snooping forwarding {vlan <vlan_name 32>}
config igmp_snooping
Purpose Used to configure IGMP snooping on the Switch.
Syntax config igmp_snooping [<vlan_name 32> | all] {host_timeout <sec 1-16711450> |
router_timeout <sec 1-16711450> | leave_timer <sec 1-16711450> | state [enable |
disable]}
Description This command allows you to configure IGMP snooping on the Switch.
Parameters <vlan_name 32>– The name of the VLAN for which IGMP snooping is to be configured.
all – Selecting this parameter will configure IGMP snooping for all VLANs on the Switch.
host_timeout <sec 1-16711450> – Specifies the maximum amount of time a host can be a member of a
multicast group without the Switch receiving a host membership report.The default is 260 seconds.
router_timeout <sec 1-16711450> – Specifies the maximum amount of time a route can be a member of a
multicast group without the Switch receiving a host membership report.The default is 260 seconds.
leave_timer <sec 1-16711450> – Leave timer.The default is 2 seconds.
state [enable | disable] Allows you to enable or disable IGMP snooping for the specified VLAN.
Restrictions Only administrator-level users can issue this command.
Example usage:
To configure the igmp snooping:
AT-9724TS:4# config igmp_snooping default host_timeout 250
state enable
Command: config igmp_snooping default host_timeout 250
state enable
S u c c e s s .
A T - 9 7 2 4 T S : 4 #
123
Allied Telesyn AT-9724TS High-Density Layer 3 Stackable Gigabit Ethernet Switch • Command Line Interface Reference Manual
