Allied Telesis AT-9724TS Reference Manual

show packet ports
Purpose Used to display statistics about the packets sent and received by the Switch.
Syntax show packet ports <portlist>
Description This command is used to display statistics about packets sent and received by ports specified in the port list.
Parameters <portlist> – Specifies a range of ports to be displayed.The port list is specified by listing the lowest switch
number and the beginning port number on that switch, separated by a colon.Then the highest switch number,
and the highest port number of the range (also separated by a colon) are specified.The beginning and end of
the port list range are separated by a dash. For example, 1:3 specifies switch number 1, port 3. 2:4 specifies
switch number 2, port 4. 1:3-2:4 specifies all of the ports between switch 1, port 3 and switch 2, port 4 – in
numerical order.
Restrictions None.
Example usage:
To display the packets analysis for port 7 of module 2:
AT-9724TS:4# show packet port 2:7
Port number : 2:7
Frame Size Frame Counts F r a m e s / s e c Frame Type T o t a l T o t a l / s e c
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
6 4 3 2 7 5 1 0 RX Bytes 4 0 8 9 7 3 1 6 5 7
6 5 - 1 2 7 7 5 5 1 0 RX Frames 4 3 9 5 1 9
1 2 8 - 2 5 5 3 1 6 1
2 5 6 - 5 1 1 1 4 5 0 TX Bytes 7 9 1 8 1 7 8
5 1 2 - 1 0 2 3 1 5 0 TX Frames 1 1 1 2
1 0 2 4 - 1 5 1 8 0 0
Unicast RX 1 5 2 1
Multicast RX 5 5 7 2
Broadcast RX 3 6 8 6 1 6
CTRL+C ESC q Quit SPACE n Next Page p Previous Page r Refresh
56
Allied Telesyn AT-9724TS High-Density Layer 3 Stackable Gigabit Ethernet Switch • Command Line Interface Reference Manual

Allied Telesis AT-9724TS Specifications

General

MAC address table	16000 entries
Packet buffer memory	2 MB
Maximum data transfer rate	88 Gbit/s
Full duplex	Yes
Dimensions (WxDxH)	440 x 210 x 44 mm
Power requirements	100-240V AC/50-60Hz
Management platform	SNMP, RMON
Networking features	IEEE 802.3 10T Ethernet, IEEE 802.3u 100TX Ethernet, IEEE 802.3ab 1000T Ethernet, IEEE 802.3z 1000X Ethernet
Connectivity technology	Wired
DHCP features	DHCP client
Security algorithms	SSH
Switch type	Managed
Switch layer	L3+
SFP/SFP+ slots quantity	4
Basic switching RJ-45 Ethernet ports quantity	24
Memory type	SDRAM / Flash
Flash memory	16 MB
Internal memory	256 MB
Power consumption (typical)	90 W
Certification	UL 1950 FCC Class A CSA 22.2 No. 950 EN55022 Class A EN 60950 (TUV) EN50082-1 CE
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Weight	3200 g
