Allied Telesis AT-9724TS Reference Manual

Status 3: STP enabled for MSTP:
AT-9724TS:4# show stp
Command: show stp
STP Status : Enabled
STP Version : MSTP
Max Age : 20
Forward Delay : 15
Max Age : 20
TX Hold Count : 3
Forwarding BPDU : Enabled
A T - 9 7 2 4 T S : 4 #
show stp ports
Purpose Used to display the Switch’s current instance_id configuration.
Syntax show stp ports <portlist>
Description This command displays the STP Instance Settings and STP Instance Operational Status currently implemented
on the Switch.
Parameters <portlist> – Specifies a range of ports to be viewed.The port list is specified by listing the lowest switch number
and the beginning port number on that switch, separated by a colon.Then the highest switch number, and the
highest port number of the range (also separated by a colon) are specified.The beginning and end of the port
list range are separated by a dash. For example, 1:3 specifies switch number 1, port 3. 2:4 specifies switch
number 2, port 4. 1:3-2:4 specifies all of the ports between switch 1, port 3 and switch 2,port 4 – in numerical
order.
Restrictions None.
Example usage:
To show stp ports 1 through 9 on switch one:
AT-9724TS:4# show stp ports 1:1-1:9
Command: show stp ports 1:1-1:9
M S T P Port Information
Port Index : 1:1, Hello Time: 2 /2, Port STP enabled
External PathCost : Auto/200000, Edge Port : No /No, P2P : Auto /Yes
M s t i Designated Bridge Internal PathCost P r i o S t a t u s R o l e
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
0 8 0 0 0 / 0 0 5 0 B A 7 1 2 0 D 6 2 0 0 0 0 0 1 2 8 F o r w a r d i n g R o o t
1 8 0 0 1 / 0 0 5 3 1 3 1 A 3 3 2 4 2 0 0 0 0 0 1 2 8 F o r w a r d i n g M a s t e r
CTRL+C ESC q Quit SPACE n Next Page p Previous Page r Refresh
76
Allied Telesyn AT-9724TS High-Density Layer 3 Stackable Gigabit Ethernet Switch • Command Line Interface Reference Manual

Allied Telesis AT-9724TS Specifications

General

MAC address table	16000 entries
Packet buffer memory	2 MB
Maximum data transfer rate	88 Gbit/s
Full duplex	Yes
Dimensions (WxDxH)	440 x 210 x 44 mm
Power requirements	100-240V AC/50-60Hz
Management platform	SNMP, RMON
Networking features	IEEE 802.3 10T Ethernet, IEEE 802.3u 100TX Ethernet, IEEE 802.3ab 1000T Ethernet, IEEE 802.3z 1000X Ethernet
Connectivity technology	Wired
DHCP features	DHCP client
Security algorithms	SSH
Switch type	Managed
Switch layer	L3+
SFP/SFP+ slots quantity	4
Basic switching RJ-45 Ethernet ports quantity	24
Memory type	SDRAM / Flash
Flash memory	16 MB
Internal memory	256 MB
Power consumption (typical)	90 W
Certification	UL 1950 FCC Class A CSA 22.2 No. 950 EN55022 Class A EN 60950 (TUV) EN50082-1 CE
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Weight	3200 g
