Allied Telesis AT-9724TS Reference Manual

show scheduling
Purpose Used to display the currently configured traffic scheduling on the Switch.
Syntax show scheduling
Description The show scheduling command displays the current configuration for the maximum number of packets
(max_packets) assigned to the seven hardware priority classes on the Switch.At this value, it will empty the
seven hardware priority classes in order, from the highest priority (queue 6) to the lowest priority (queue 0).
Parameters None.
Restrictions None.
Example usage:
To display the current scheduling configuration with Class 1 as the strict priority class of a Combination Queue:
AT-9724TS:4# show scheduling
Command: show scheduling
QOS Output Scheduling
MAX. Packets
- - - - - - - - - - - -
C l a s s - 0 1
C l a s s - 1 0
C l a s s - 2 3
C l a s s - 3 4
C l a s s - 4 5
C l a s s - 5 6
C l a s s - 6 7
A T - 9 7 2 4 T S : 4 #
94
Allied Telesyn AT-9724TS High-Density Layer 3 Stackable Gigabit Ethernet Switch • Command Line Interface Reference Manual

Allied Telesis AT-9724TS Specifications

General

MAC address table	16000 entries
Packet buffer memory	2 MB
Maximum data transfer rate	88 Gbit/s
Full duplex	Yes
Dimensions (WxDxH)	440 x 210 x 44 mm
Power requirements	100-240V AC/50-60Hz
Management platform	SNMP, RMON
Networking features	IEEE 802.3 10T Ethernet, IEEE 802.3u 100TX Ethernet, IEEE 802.3ab 1000T Ethernet, IEEE 802.3z 1000X Ethernet
Connectivity technology	Wired
DHCP features	DHCP client
Security algorithms	SSH
Switch type	Managed
Switch layer	L3+
SFP/SFP+ slots quantity	4
Basic switching RJ-45 Ethernet ports quantity	24
Memory type	SDRAM / Flash
Flash memory	16 MB
Internal memory	256 MB
Power consumption (typical)	90 W
Certification	UL 1950 FCC Class A CSA 22.2 No. 950 EN55022 Class A EN 60950 (TUV) EN50082-1 CE
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Weight	3200 g
