Chapter 5 - Switch Port Commands
The switch port commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table.
Command Parameters
config ports [<portlist | all {speed [auto | 10_half | 10_full | 100_half | 100_full | 1000_full [master | slave]} | flow_control
[enable | disable] | learning [enable | disable] state [enable | disable] description <desc 32> | clear]
show ports <portlist>
Each command is listed, in detail, in the following sections:
config ports
Purpose Used to configure the Switch’s Ethernet port settings.
Syntax
[<portlist> | all {speed [auto | 10_half
| 10_full | 100_half
| 100_full | 1000_f
ull [master
|slave]} | flow_control [enable | disable] | learning [enable | disable] state [enable |
disable] description <desc 32> | clear]
Description This command allows for the configuration of the Switch’s Ethernet ports. Only the ports listed in the
<portlist> will be affected.
Parameters all – Configure all ports on the Switch.
<portlist> – Specifies a range of ports to be configured.The port list is specified by listing the lowest switch
number and the beginning port number on that switch, separated by a colon.Then the highest switch number,
and the highest port number of the range (also separated by a colon) are specified.The beginning and end of
the port list range are separated by a dash. For example, 1:3 specifies switch number 1, port 3. 2:4 specifies
switch number 2, port 4. 1:3-2:4 specifies all of the ports between switch 1, port 3 and switch 2, port 4 – in
numerical order.
auto – Enables auto-negotiation for the specified range of ports.
[10 | 100 | 1000] – Configures the speed in Mbps for the specified range of ports.
[half | full] – Configures the specified range of ports as either full- or half-duplex.
[master | slave] – The master and slave parameters refer to connections running a 1000T cable for connection
between the Switch port and other device capable of a gigabit connection.The master setting will allow the
port to advertise capabilities related to duplex, speed and physical layer type.The master setting will also
determine the master and slave relationship between the two connected physical layers.This relationship is
necessary for establishing the timing control between the two physical layers.The timing control is set on a
master physical layer by a local source.The slave setting uses loop timing, where the timing comes form a data
stream received from the master. If one connection is set for 1000 master, the other side of the connection
must be set for 1000 slave.Any other configuration will result in a link down status for both ports.
flow_control [enable | disable] – Enable or disable flow control for the specified ports.
learning [enable | disable] – Enables or disables the MAC address learning on the specified range of ports.
state [enable | disable] – Enables or disables the specified range of ports.
description <desc 32> - Enter an alphanumeric string of no more than 32 characters to describe a selected port
interface.
clear – Enter this command to clear the port description of the selected port(s).
Restrictions Only administrator-level users can issue this command.
Example usage:
To configure the speed of port 3 to be 10 Mbps, full duplex, learning and state enable:
AT-9724TS:4# config ports 1:1-1:3 speed 10_full learning
enable state enable
Command:config ports 1:1-1:3 speed 10_full learning
enable state enable
S u c c e s s .
A T - 9 7 2 4 T S : 4 #
28
Allied Telesyn AT-9724TS High-Density Layer 3 Stackable Gigabit Ethernet Switch • Command Line Interface Reference Manual
