Page #31 background imageLoading...
Page #31 background image
Chapter 6 - Port Security Commands
The port security commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table.
Command Parameters
config ports [<portlist>| all ] {admin_state [enable | disable] | max_learning_addr <max_lock_no 0-64> |
lock_address_mode [Permanent | DeleteOnTimeout | DeleteOnReset]}
show port_security {ports <portlist>}
delete port_security_entry_ <vlan_name 32> port <port> mac_address <macaddr>
vlan_name
Each command is listed, in detail, in the following sections:
config port_security ports
Purpose Used to configure port security settings.
Syntax [<portlist>| all ] {admin_state [enable | disable] | max_learning_addr <max_lock_no 0-
64> | lock_address_mode [Permanent | DeleteOnTimeout | DeleteOnReset]}
Description This command allows for the configuration of the port security feature. Only the ports listed in the <portlist>
are effected.
Parameters <portlist> – Specifies a range of ports to be configured.The port list is specified by listing the lowest switch
number and the beginning port number on that switch, separated by a colon.Then the highest switch number,
and the highest port number of the range (also separated by a colon) are specified.The beginning and end of
the port list range are separated by a dash. For example, 1:3 specifies switch number 1, port 3. 2:4 specifies
switch number 2, port 4. 1:3-2:4 specifies all of the ports between switch 1, port 3 and switch 2, port 4 – in
numerical order.
all – Configure port security for all ports on the Switch.
admin_state [enable | disable] – Enable or disable port security for the listed ports.
max_learning_addr <max_lock_no 0-64> - Use this to limit the number of MAC addresses dynamically listed in
the FDB for the ports.
lock_address_mode [Permanent | DeleteOnTimeout | DeleteOnReset] – Indicates the method of locking addresses.
The user has three choices:
Permanent – The locked addresses will not age out after the aging timer expires.
DeleteOnTimeout – The locked addresses will age out after the aging timer expires.
DeleteOnReset – The locked addresses will not age out until the Switch has been reset.
Restrictions Only administrator-level users can issue this command.
Example usage:
To configure the port security:
AT-9724TS:4# config port_security ports 5:1-5:5 admin_state
enable max_learning_addr 5 lock_address_mode DeleteOnReset
Command:config port_security ports 5:1-5:5 admin_state
enable max_learning_addr 5 lock_address_mode DeleteOnReset
S u c c e s s .
A T - 9 7 2 4 T S : 4 #
30
Allied Telesyn AT-9724TS High-Density Layer 3 Stackable Gigabit Ethernet Switch • Command Line Interface Reference Manual
