show ports
Purpose Used to display the current configuration of a range of ports.
Syntax show ports <portlist> {description}
Description This command is used to display the current configuration of a range of ports
Parameters portlist> – Specifies a range of ports to be displayed.The port list is specified by listing the lowest switch
number and the beginning port number on that switch, separated by a colon.Then the highest switch number,
and the highest port number of the range (also separated by a colon) are specified.The beginning and end of
the port list range are separated by a dash. For example, 1:3 specifies switch number 1, port 3. 2:4 specifies
switch number 2, port 4. 1:3-2:4 specifies all of the ports between switch 1, port 3 and switch 2, port 4 – in
numerical order.
{description} – Adding this parameter to the command will allow the user to view previously configured
description set on various ports on the Switch.
Restrictions None.
Example usage:
To display the configuration of all ports on a standalone switch:
AT-9724TS:4# show ports
Command:show ports
P o r t P o r t Settings Speed/ Connection Speed/ A d d r e s s
S t a t e D u p l e x / D u p l e x / L e a r n i n g
Flow Control Flow Control
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
1 : 1 E n a b l e d A u t o / E n a b l e d Link Down E n a b l e d
1 : 2 E n a b l e d A u t o / E n a b l e d Link Down E n a b l e d
1 : 3 E n a b l e d A u t o / E n a b l e d Link Down E n a b l e d
1 : 4 E n a b l e d A u t o / E n a b l e d Link Down E n a b l e d
1 : 5 E n a b l e d A u t o / E n a b l e d Link Down E n a b l e d
1 : 6 Enabled A u t o / E n a b l e d Link Down E n a b l e d
1 : 7 E n a b l e d A u t o / E n a b l e d Link Down E n a b l e d
1 : 8 E n a b l e d A u t o / E n a b l e d Link Down E n a b l e d
1 : 9 E n a b l e d A u t o / E n a b l e d Link Down E n a b l e d
1 : 1 0 E n a b l e d A u t o / E n a b l e d 1 0 0 M / F u l l / 8 0 2 . 3 x E n a b l e d
1 : 1 1 E n a b l e d A u t o / E n a b l e d Link Down E n a b l e d
1 : 1 2 E n a b l e d A u t o / E n a b l e d Link Down E n a b l e d
1 : 1 3 E n a b l e d A u t o / D i s a b l e d Link Down E n a b l e d
1 : 1 4 E n a b l e d A u t o / D i s a b l e d Link Down E n a b l e d
1 : 1 5 E n a b l e d A u t o / D i s a b l e d Link Down E n a b l e d
1 : 1 6 E n a b l e d A u t o / D i s a b l e d Link Down E n a b l e d
1 : 1 7 E n a b l e d A u t o / D i s a b l e d Link Down E n a b l e d
1 : 1 8 E n a b l e d A u t o / D i s a b l e d Link Down E n a b l e d
1 : 1 9 E n a b l e d A u t o / D i s a b l e d Link Down E n a b l e d
1 : 2 0 E n a b l e d A u t o / D i s a b l e d Link Down E n a b l e d
CTRL+C ESC q Quit SPACE n Next Page p Previous Page r Refresh
Example usage:
To display port descriptions:
AT-9724TS:4# show ports 1:1 description
Command:show ports 1:1 description
P o r t P o r t Settings Speed/ Connection Speed/ A d d r e s s
S t a t e D u p l e x / D u p l e x / L e a r n i n g
Flow Control Flow Control
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
1 : 1 E n a b l e d A u t o / E n a b l e d Link Down E n a b l e d
Description: Accounting
A T - 9 7 2 4 T S : 4 #
29
Allied Telesyn AT-9724TS High-Density Layer 3 Stackable Gigabit Ethernet Switch • Command Line Interface Reference Manual

Allied Telesis AT-9724TS Specifications

General

MAC address table	16000 entries
Packet buffer memory	2 MB
Maximum data transfer rate	88 Gbit/s
Full duplex	Yes
Dimensions (WxDxH)	440 x 210 x 44 mm
Power requirements	100-240V AC/50-60Hz
Management platform	SNMP, RMON
Networking features	IEEE 802.3 10T Ethernet, IEEE 802.3u 100TX Ethernet, IEEE 802.3ab 1000T Ethernet, IEEE 802.3z 1000X Ethernet
Connectivity technology	Wired
DHCP features	DHCP client
Security algorithms	SSH
Switch type	Managed
Switch layer	L3+
SFP/SFP+ slots quantity	4
Basic switching RJ-45 Ethernet ports quantity	24
Memory type	SDRAM / Flash
Flash memory	16 MB
Internal memory	256 MB
Power consumption (typical)	90 W
Certification	UL 1950 FCC Class A CSA 22.2 No. 950 EN55022 Class A EN 60950 (TUV) EN50082-1 CE
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Weight	3200 g
