Allied Telesis AT-9724TS Reference Manual

show ospf lsdb
Purpose Used to display the OSPF Link State Database (LSDB).
Syntax show ospf lsdb {area_id <area_id> | advertise_router
<ipaddr> | type [rtrlink | netlink | summary | assummary | asextlink]}
Description This command will display the current OSPF Link State Database (LSDB).
Parameters area_id <area_id> – A 32-bit number in the form of an IP address (xxx.xxx.xxx.xxx) that uniquely identifies the
OSPF area in the OSPF domain.
advertise_router <ipaddr> – The router ID of the advertising router.
type [rtrlink | netlink | summary | assummary | asextlink] – The type of link.
Restrictions None.
Example usage:
To display OSPF area aggregation settings:
AT-9724TS:4# show ospf aggregation
Command: show ospf aggregation
OSPF Area Aggregation Settings
Area ID A g g r e g a t e d L S D B A d v e r t i s e
Network Address T y p e
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
1 0 . 1 . 1 . 1 1 0 . 0 . 0 . 0 / 8 S u m m a r y E n a b l e d
1 0 . 1 . 1 . 1 2 0 . 2 . 0 . 0 / 1 6 S u m m a r y E n a b l e d
Total Entries: 2
A T - 9 7 2 4 T S : 4 #
Note: When this command displays a “*” (a star symbol) in the OSPF LSDB table for the area_id or the Cost, this is interpreted as “no area ID”
for external LSAs, and as “no cost given” for the advertised link.
Example usage:
To display the link state database of OSPF:
AT-9724TS:4# show ospf lsdb
Command: show ospf lsdb
A r e a L S D B A d v e r t i s i n g Link State C o s t S e q u e n c e
I D T y p e Router ID I D N u m b e r
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
0 . 0 . 0 . 0 R T R L i n k 5 0 . 4 8 . 7 5 . 7 3 5 0 . 4 8 . 7 5 . 7 3 * 0 x 8 0 0 0 0 0 0 2
0 . 0 . 0 . 0 S u m m a r y 5 0 . 4 8 . 7 5 . 7 3 1 0 . 0 . 0 . 0 / 8 1 0 x 8 0 0 0 0 0 0 1
1 . 0 . 0 . 0 R T R L i n k 5 0 . 4 8 . 7 5 . 7 3 5 0 . 4 8 . 7 5 . 7 3 * 0 x 8 0 0 0 0 0 0 1
1 . 0 . 0 . 0 S u m m a r y 5 0 . 4 8 . 7 5 . 7 3 4 0 . 0 . 0 . 0 / 8 1 0 x 8 0 0 0 0 0 0 1
1 . 0 . 0 . 0 S u m m a r y 5 0 . 4 8 . 7 5 . 7 3 5 0 . 0 . 0 . 0 / 8 1 0 x 8 0 0 0 0 0 0 1
* A S E x t L i n k 5 0 . 4 8 . 7 5 . 7 3 1 . 2 . 0 . 0 / 1 6 2 0 0 x 8 0 0 0 0 0 0 1
Total Entries: 5
A T - 9 7 2 4 T S : 4 #
259
Allied Telesyn AT-9724TS High-Density Layer 3 Stackable Gigabit Ethernet Switch • Command Line Interface Reference Manual

Allied Telesis AT-9724TS Specifications

General

MAC address table	16000 entries
Packet buffer memory	2 MB
Maximum data transfer rate	88 Gbit/s
Full duplex	Yes
Dimensions (WxDxH)	440 x 210 x 44 mm
Power requirements	100-240V AC/50-60Hz
Management platform	SNMP, RMON
Networking features	IEEE 802.3 10T Ethernet, IEEE 802.3u 100TX Ethernet, IEEE 802.3ab 1000T Ethernet, IEEE 802.3z 1000X Ethernet
Connectivity technology	Wired
DHCP features	DHCP client
Security algorithms	SSH
Switch type	Managed
Switch layer	L3+
SFP/SFP+ slots quantity	4
Basic switching RJ-45 Ethernet ports quantity	24
Memory type	SDRAM / Flash
Flash memory	16 MB
Internal memory	256 MB
Power consumption (typical)	90 W
Certification	UL 1950 FCC Class A CSA 22.2 No. 950 EN55022 Class A EN 60950 (TUV) EN50082-1 CE
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Weight	3200 g
