Page #119 background imageLoading...
Page #119 background image
config ipif
Purpose Used to configure the System IP interface.
Syntax config ipif <ipif_name 12> [ ipaddress <network_address> | vlan <vlan_name 32> | state
[enable | disable] | bootp | dhcp}]
Description This command is used to configure the System IP interface on the Switch.
Parameters <ipif_name 12> - Enter the previously created IP interface name desired to be configured.
ipaddress <network_address> – IP address and netmask of the IP interface to be configured.The address and
mask information can be specified using the traditional format (for example, 10.1.2.3/255.0.0.0 or in CIDR
format, 10.1.2.3/8).
vlan <vlan_name 32> The name of the VLAN corresponding to the previously created IP interface. If a primary
and secondary IP interface are configured for the same VLAN (subnet), the user cannot change the VLAN of
the IP interface.
state [enable | disable] Allows you to enable or disable the IP interface.
bootp Allows the selection of the BOOTP protocol for the assignment of an IP address to the Switch’s System
IP interface.
dhcp Allows the selection of the DHCP protocol for the assignment of an IP address to the Switch’s System
IP interface.
Restrictions Only administrator-level users can issue this command.
Example usage:
To configure the IP interface System:
AT-9724TS:4# config ipif System ipaddress 10.48.74.122/8
Command: config ipif System ipaddress 10.48.74.122/8
S u c c e s s .
A T - 9 7 2 4 T S : 4 #
enable ipif
Purpose Used to enable an System IP interface on the Switch.
Syntax enable ipif {<ipif_name 12> | all}
Description This command will enable the IP interface function on the Switch.
Parameters <ipif_name 12> The name of a previously configured IP interface the user wishes to enable. Enter an
alphanumeric entry of up to twelve characters to define the IP interface.
all – Entering this parameter will enable all the IP interfaces currently configured on the Switch.
Restrictions None.
Example usage:
To enable the ipif function on the Switch:
AT-9724TS:4# enable ipif s2
Command: enable ipif s2
S u c c e s s .
A T - 9 7 2 4 T S : 4 #
118
Allied Telesyn AT-9724TS High-Density Layer 3 Stackable Gigabit Ethernet Switch • Command Line Interface Reference Manual
