Chapter 26 - Traffic Segmentation Commands
Traffic segmentation allows you to further sub-divide VLANs into smaller groups of ports that will help to reduce traffic on the VLAN.The VLAN rules take
precedence, and then the traffic segmentation rules are applied.The traffic segmentation commands in the Command Line Interface (CLI) are listed (along with
the appropriate parameters) in the following table.
Command Parameters
config traffic_segmentation [<portlist> | all] forward_list [null | all | <portlist>]
show traffic_segmentation {<portlist>}
Each command is listed, in detail, in the following sections.
config traffic_segmentation
Purpose Used to configure traffic segmentation on the Switch.
Syntax config traffic_segmentation [<portlist> | all] forward_list [null | all | <portlist>]
Description The config traffic_segmentation command is used to configure traffic segmentation on the Switch.
Parameters <portlist> – Specifies a range of ports that will be configured for traffic segmentation.The port list is specified
by listing the lowest switch number and the beginning port number on that switch, separated by a colon.Then
the highest switch number, and the highest port number of the range (also separated by a colon) are specified.
The beginning and end of the port list range are separated by a dash. For example, 1:3 specifies switch number
1, port 3. 2:4 specifies switch number 2, port 4. 1:3-2:4 specifies all of the ports between switch 1, port 3 and
switch 2, port 4 – in numerical order.
all – Specifies all ports on the Switch.
forward_list – Specifies a range of ports that will receive forwarded frames from the ports specified in the
portlist, above.
null – no ports are specified
<portlist> – Specifies a range of ports for the forwarding list.This list must be on the same switch previously
specified for traffic segmentation (i.e. following the <portlist> specified above for config
traffic_segmentation).The port list is specified by listing the lowest switch number and the beginning port
number on that switch, separated by a colon.Then the highest switch number, and the highest port number of
the range (also separated by a colon) are specified.The beginning and end of the port list range are separated
by a dash. For example, 1:3 specifies switch number 1, port 3. 2:4 specifies switch number 2, port 4. 1:3-2:4
specifies all of the ports between switch 1, port 3 and switch 2, port 4 – in numerical order.
Restrictions Only administrator-level users can issue this command.
Example usage:
To configure ports 1 through 10 to be able to forward frames to port 11 through 15:
AT-9724TS:4# config traffic_segmentation 1:1-1:10
forward_list 1:11-1:15
Command: config traffic_segmentation 1:1-1:10
forward_list 1:11-1:15
S u c c e s s .
A T - 9 7 2 4 T S : 4 #
191
Allied Telesyn AT-9724TS High-Density Layer 3 Stackable Gigabit Ethernet Switch • Command Line Interface Reference Manual
