Page #230 background imageLoading...
Page #230 background image
Chapter 34 - BOOTP Relay Commands
The BOOTP relay commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table.
Command Parameters
config bootp_relay {hops <value 1-16> | time <sec 0-65535>}
config bootp_relay add ipif
config bootp_relay delete ipif <ipif_name 12> <ipaddr>
enable bootp_relay
disable bootp_relay
show bootp_relay {ipif <ipif_name 12>}
Each command is listed, in detail, in the following sections:
config bootp_relay
Purpose Used to configure the BOOTP relay feature of the Switch.
Syntax config bootp_relay {hops <value 1-16>} {time <sec 0-65535>}
Description This command is used to configure the BOOTP relay feature.
Parameters hops <value 1-16> – Specifies the maximum number of relay agent hops that the BOOTP packets can cross.
time <sec 0-65535> – If this time is exceeded, the Switch will relay the BOOTP packet.
Restrictions Only administrator-level users can issue this command.
Example usage:
To configure bootp relay status:
AT-9724TS:4# config bootp_relay hops 4 time 2
Command: config bootp_relay hops 4 time 2
S u c c e s s .
A T - 9 7 2 4 T S : 4 #
config bootp_relay add
Purpose Used to add an IP destination address to the Switch’s BOOTP relay table.
Syntax config bootp_relay add ipif <ipif_name 12> <ipaddr>
Description This command adds an IP address as a destination to forward (relay) BOOTP packets to.
Parameters <ipif_name 12> – The name of the IP interface in which BOOTP relay is to be enabled.
<ipaddr> The BOOTP server IP address.
Restrictions Only administrator-level users can issue this command.
Example usage:
To add a bootp relay:
AT-9724TS:4# config bootp_relay add ipif System 10.43.21.12
Command: config bootp_relay add ipif System 10.43.21.12
S u c c e s s .
A T - 9 7 2 4 T S : 4 #
229
Allied Telesyn AT-9724TS High-Density Layer 3 Stackable Gigabit Ethernet Switch • Command Line Interface Reference Manual
