Page #110 background imageLoading...
Page #110 background image
show vlan
Purpose Used to display the current VLAN configuration on the Switch.
Syntax show vlan {<vlan_name 32>}
Description This command displays summary information about each VLAN including the VLAN ID,VLAN name, the
Tagging/Untagging status, and the Member/Non-member/Forbidden status of each port that is a member of the
VLAN.
Parameters <vlan_name 32> The VLAN name of the VLAN for which you want to display a summary of settings.
Restrictions None.
Example usage:
To display the Switch’s current VLAN settings:
AT-9724TS:4# show vlan
Command: show vlan
V I D : 1 VLAN Name : default
VLAN TYPE : 1QVLAN Protocol ID :
U s e r D e f i n e d P i d : A d v e r t i s e m e n t : Enabled
E n c a p :
Member ports : 1:1-1:24,2:1-2:24
Static ports : 1:1-1:24,2:1-2:24
Untagged ports : 1:1-1:24,2:1-2:24
Forbidden ports :
V I D : 2 VLAN Name : v1
VLAN TYPE : PROTOCOL Protocol ID : ip
U s e r D e f i n e d P i d : A d v e r t i s e m e n t : Enabled
E n c a p :
Member ports : 1:1-1:24,2:1-2:24
Static ports : 1:24,2:24
Untagged ports :
Forbidden ports :
Total Entries : 2
A T - 9 7 2 4 T S : 4 #
109
Allied Telesyn AT-9724TS High-Density Layer 3 Stackable Gigabit Ethernet Switch • Command Line Interface Reference Manual
