Allied Telesis AT-9724TS Reference Manual

Chapter 22 - SSH Commands
The steps required to use the SSH protocol for secure communication between a remote PC (the SSH Client) and the Switch (the SSH Server), are as follows:
Create a user account with admin-level access using the create account admin <username> <password> command.This is identical to
creating any other admin-lever User account on the Switch, including specifying a password.This password is used to login to the Switch, once secure
communication has been established using the SSH protocol.
Configure the user account to use a specified authorization method to identify users that are allowed to establish SSH connections with the Switch
using the config ssh user authmode command.There are three choices as to the method SSH will use to authorize the user, and they are
password,publickey and hostbased.
Configure the encryption algorithm that SSH will use to encrypt and decrypt messages sent between the SSH Client and the SSH Server.
Finally, enable SSH on the Switch using the enable ssh command.
After following the above steps, you can configure an SSH Client on the remote PC and manage the Switch using secure, in-band communication.
The Secure Shell (SSH) commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following table.
Command Parameters
enable ssh
disable ssh
config ssh authmode [password | publickey | hostbased] [enable | disable]
show ssh authmode
config ssh server {maxsession <int 1-3> | contimeout <sec 120-600> | authfail <int 2-20> | rekey [10min | 30min | 60min |
never]
show ssh server
config ssh user <username> authmode {hostbased [hostname <string 32> | hostname_IP <string 32> <ipaddr>} | password |
publickey | none]
show ssh user authmode
config ssh algorithm [3DES | AES128 | AES192 | AES256 | arcfour | blowfish | cast128 | twofish128 | twofish192 | twofish256 | MD5 |
SHA1 | DSA | RSA] [enable | disable]
show ssh algorithm
Each command is listed, in detail, in the following sections:
enable shh
Purpose Used to enable SSH.
Syntax enable ssh
Description This command allows you to enable SSH on the Switch.
Parameters None.
Restrictions Only administrator-level users can issue this command.
Example usage:
To enable SSH:
AT-9724TS:4# enable ssh
Command: enable ssh
S u c c e s s .
A T - 9 7 2 4 T S : 4 #
154
Allied Telesyn AT-9724TS High-Density Layer 3 Stackable Gigabit Ethernet Switch • Command Line Interface Reference Manual

Allied Telesis AT-9724TS Specifications

General

MAC address table	16000 entries
Packet buffer memory	2 MB
Maximum data transfer rate	88 Gbit/s
Full duplex	Yes
Dimensions (WxDxH)	440 x 210 x 44 mm
Power requirements	100-240V AC/50-60Hz
Management platform	SNMP, RMON
Networking features	IEEE 802.3 10T Ethernet, IEEE 802.3u 100TX Ethernet, IEEE 802.3ab 1000T Ethernet, IEEE 802.3z 1000X Ethernet
Connectivity technology	Wired
DHCP features	DHCP client
Security algorithms	SSH
Switch type	Managed
Switch layer	L3+
SFP/SFP+ slots quantity	4
Basic switching RJ-45 Ethernet ports quantity	24
Memory type	SDRAM / Flash
Flash memory	16 MB
Internal memory	256 MB
Power consumption (typical)	90 W
Certification	UL 1950 FCC Class A CSA 22.2 No. 950 EN55022 Class A EN 60950 (TUV) EN50082-1 CE
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Weight	3200 g
