Allied Telesis AT-9724TS Reference Manual

show traffic_segmentation
Purpose Used to display the current traffic segmentation configuration on the Switch.
Syntax show traffic_segmentation <portlist>
Description The show traffic_segmentation command is used to display the current traffic segmentation
configuration on the Switch.
Parameters <portlist> – Specifies a range of ports that will be configured for traffic segmentation.The port list is specified
by listing the lowest switch number and the beginning port number on that switch, separated by a colon.Then
the highest switch number, and the highest port number of the range (also separated by a colon) are specified.
The beginning and end of the port list range are separated by a dash. For example, 1:3 specifies switch number
1, port 3. 2:4 specifies switch number 2, port 4. 1:3-2:4 specifies all of the ports between switch 1, port 3 and
switch 2, port 4 – in numerical order.
Restrictions The port lists for segmentation and the forward list must be on the same Switch.
Example usage:
To display the current traffic segmentation configuration on the Switch:
AT-9724TS:4# show traffic_segmentation
Command: show traffic_segmentation
Traffic Segmentation Table
P o r t Forward Portlist
- - - - - - - - - - - - - - - - - - - -
1 : 1 1 : 1 - 1 : 2 4 , 2 : 1 - 2 : 2 4
1 : 2 1 : 1 - 1 : 2 4 , 2 : 1 - 2 : 2 4
1 : 3 1 : 1 - 1 : 2 4 , 2 : 1 - 2 : 2 4
1 : 4 1 : 1 - 1 : 2 4 , 2 : 1 - 2 : 2 4
1 : 5 1 : 1 - 1 : 2 4 , 2 : 1 - 2 : 2 4
1 : 6 1 : 1 - 1 : 2 4 , 2 : 1 - 2 : 2 4
1 : 7 1 : 1 - 1 : 2 4 , 2 : 1 - 2 : 2 4
1 : 8 1 : 1 - 1 : 2 4 , 2 : 1 - 2 : 2 4
1 : 9 1 : 1 - 1 : 2 4 , 2 : 1 - 2 : 2 4
1 : 1 0 1 : 1 - 1 : 2 4 , 2 : 1 - 2 : 2 4
1 : 1 1 1 : 1 - 1 : 2 4 , 2 : 1 - 2 : 2 4
1 : 1 2 1 : 1 - 1 : 2 4 , 2 : 1 - 2 : 2 4
1 : 1 3 1 : 1 - 1 : 2 4 , 2 : 1 - 2 : 2 4
1 : 1 4 1 : 1 - 1 : 2 4 , 2 : 1 - 2 : 2 4
1 : 1 5 1 : 1 - 1 : 2 4 , 2 : 1 - 2 : 2 4
1 : 1 6 1 : 1 - 1 : 2 4 , 2 : 1 - 2 : 2 4
1 : 1 7 1 : 1 - 1 : 2 4 , 2 : 1 - 2 : 2 4
1 : 1 8 1 : 1 - 1 : 2 4 , 2 : 1 - 2 : 2 4
CTRL+C ESC q Quit SPACE n Next Page Enter Next Entry a All
A T - 9 7 2 4 T S : 4 #
192
Allied Telesyn AT-9724TS High-Density Layer 3 Stackable Gigabit Ethernet Switch • Command Line Interface Reference Manual

Allied Telesis AT-9724TS Specifications

General

MAC address table	16000 entries
Packet buffer memory	2 MB
Maximum data transfer rate	88 Gbit/s
Full duplex	Yes
Dimensions (WxDxH)	440 x 210 x 44 mm
Power requirements	100-240V AC/50-60Hz
Management platform	SNMP, RMON
Networking features	IEEE 802.3 10T Ethernet, IEEE 802.3u 100TX Ethernet, IEEE 802.3ab 1000T Ethernet, IEEE 802.3z 1000X Ethernet
Connectivity technology	Wired
DHCP features	DHCP client
Security algorithms	SSH
Switch type	Managed
Switch layer	L3+
SFP/SFP+ slots quantity	4
Basic switching RJ-45 Ethernet ports quantity	24
Memory type	SDRAM / Flash
Flash memory	16 MB
Internal memory	256 MB
Power consumption (typical)	90 W
Certification	UL 1950 FCC Class A CSA 22.2 No. 950 EN55022 Class A EN 60950 (TUV) EN50082-1 CE
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Weight	3200 g
