Allied Telesis AT-9724TS Reference Manual

show igmp
Purpose Used to display the IGMP configuration for the Switch of for a specified IP interface.
Syntax show igmp {ipif <ipif_name 12>}
Description This command will display the IGMP configuration for the Switch if no IP interface name is specified. If an IP
interface name is specified, the command will display the IGMP configuration for that IP interface.
Parameters <ipif_name 12> – The name of the IP interface for which the IGMP configuration will be displayed.
Restrictions None.
Example usage:
To display IGMP configurations:
AT-9724TS:4# show igmp
Command: show igmp
IGMP Interface Configurations
I n t e r f a c e IP Address V e r s i o n - Q u e r y M a x i m u m R o b u s t - L a s t S t a t e
/ N e t m a s k R e s p o n s e n e s s M e m b e r
T i m e V a l u e Q u e r y
I n t e r v a l
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
S y s t e m 1 0 . 9 0 . 9 0 . 9 0 / 8 1 1 2 5 1 0 2 1 E n a b l e d
p 1 2 0 . 1 . 1 . 1 / 8 1 1 2 5 1 0 2 1 E n a b l e d
Total Entries: 2
A T - 9 7 2 4 T S : 4 #
show igmp group
Purpose Used to display the Switch’s IGMP group table.
Syntax show igmp group {group <group>} {ipif <ipif_name 12>}
Description This command will display the IGMP group configuration.
Parameters group <group> – The multicast group ID which the user wishes to display.
<ipif_name 12> – The name of the IP interface the IGMP group is part of.
Restrictions None.
Example usage:
To display IGMP group table:
AT-9724TS:4# show igmp group
Command: show igmp group
I n t e r f a c e M u l t i c a s t L a s t - I P Q u e r i e r I P Expire Time
N a m e G r o u p R e p o r t e r
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
S y s t e m 2 2 4 . 0 . 0 . 2 1 0 . 4 2 . 7 3 . 1 1 1 1 0 . 4 8 . 7 4 . 1 2 2 2 6 0
S y s t e m 2 2 4 . 0 . 0 . 9 1 0 . 2 0 . 5 3 . 1 1 0 . 4 8 . 7 4 . 1 2 2 2 6 0
S y s t e m 2 2 4 . 0 . 1 . 2 4 1 0 . 1 8 . 1 . 3 1 0 . 4 8 . 7 4 . 1 2 2 2 5 9
S y s t e m 2 2 4 . 0 . 1 . 4 1 1 0 . 1 . 4 3 . 2 5 2 1 0 . 4 8 . 7 4 . 1 2 2 2 5 9
Total Entries: 5
A T - 9 7 2 4 T S : 4 #
122
Allied Telesyn AT-9724TS High-Density Layer 3 Stackable Gigabit Ethernet Switch • Command Line Interface Reference Manual

Allied Telesis AT-9724TS Specifications

General

MAC address table	16000 entries
Packet buffer memory	2 MB
Maximum data transfer rate	88 Gbit/s
Full duplex	Yes
Dimensions (WxDxH)	440 x 210 x 44 mm
Power requirements	100-240V AC/50-60Hz
Management platform	SNMP, RMON
Networking features	IEEE 802.3 10T Ethernet, IEEE 802.3u 100TX Ethernet, IEEE 802.3ab 1000T Ethernet, IEEE 802.3z 1000X Ethernet
Connectivity technology	Wired
DHCP features	DHCP client
Security algorithms	SSH
Switch type	Managed
Switch layer	L3+
SFP/SFP+ slots quantity	4
Basic switching RJ-45 Ethernet ports quantity	24
Memory type	SDRAM / Flash
Flash memory	16 MB
Internal memory	256 MB
Power consumption (typical)	90 W
Certification	UL 1950 FCC Class A CSA 22.2 No. 950 EN55022 Class A EN 60950 (TUV) EN50082-1 CE
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Weight	3200 g
