Allied Telesis AT-9724TS Reference Manual

upload
Purpose Used to upload the current switch settings or the switch history log to a TFTP server or a CompactFlash
memory card.
Syntax upload [cfg_toTFTP <ipaddr> <path_filename 64> | log_toTFTP <ipaddr> <path_filename
64>]
Description This command is used to upload either the Switch’s current settings, the Switch’s history log or firmware to a
TFTP.
Parameters cfg_toTFTP – Specifies that the Switch’s current settings will be uploaded to the TFTP server.
log_toTFTP – Specifies that the Switch’s current log will be uploaded to the TFTP server.
<ipaddr> – The IP address of the TFTP server.The TFTP server must be on the same IP subnet as the Switch.
<path_filename 64> – Specifies the location of the Switch configuration file on the TFTP server.This file will be
replaced by the uploaded file from the Switch.
Restrictions The TFTP server must be on the same IP subnet as the Switch. Only administrator-level users can issue this
command.
Example usage:
To upload a configuration file:
AT-9724TS:4# upload cfg_toTFTP 10.48.74.121 c:\cfg\log.txt
Command: upload cfg_to TFTP 10.48.74.121 c:\cfg\log.txt
Connecting to server................... Done.
Upload configuration............. Done.
A T - 9 7 2 4 T S : 4 #
show firmware information
Purpose Used to display the firmware section information.
Syntax show firmware information
Description This command is used to display the firmware section information.
Parameters None.
Restrictions None.
Example usage:
To display the current firmware information on the Switch:
AT-9724TS:4# show firmware information
Command: show firmware information
Box ID V e r s i o n Size (B) Update Time F r o m U s e r
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
1 * 1 3 . 0 0 - B 1 4 2 3 6 0 4 7 1 00000 days 00:00:00 Serial Port (PROM) U n k n o w n
1 2 3 . 0 0 - B 1 3 1 0 5 2 3 7 2 00000 days 00:00:00 1 0 . 5 3 . 1 3 . 9 4 A n o n y m o u s
* means boot up section
( R ) means firmware update thru SerialPort (RS232)
(T) means firmware update thru TELNET
( S ) means firmware update thru SNMP
(W) means firmware update thru WEB
(SIM) means firmware update thru Single IP M a n a g e m e n t
A T - 9 7 2 4 T S : 4 #
51
Allied Telesyn AT-9724TS High-Density Layer 3 Stackable Gigabit Ethernet Switch • Command Line Interface Reference Manual

Allied Telesis AT-9724TS Specifications

General

MAC address table	16000 entries
Packet buffer memory	2 MB
Maximum data transfer rate	88 Gbit/s
Full duplex	Yes
Dimensions (WxDxH)	440 x 210 x 44 mm
Power requirements	100-240V AC/50-60Hz
Management platform	SNMP, RMON
Networking features	IEEE 802.3 10T Ethernet, IEEE 802.3u 100TX Ethernet, IEEE 802.3ab 1000T Ethernet, IEEE 802.3z 1000X Ethernet
Connectivity technology	Wired
DHCP features	DHCP client
Security algorithms	SSH
Switch type	Managed
Switch layer	L3+
SFP/SFP+ slots quantity	4
Basic switching RJ-45 Ethernet ports quantity	24
Memory type	SDRAM / Flash
Flash memory	16 MB
Internal memory	256 MB
Power consumption (typical)	90 W
Certification	UL 1950 FCC Class A CSA 22.2 No. 950 EN55022 Class A EN 60950 (TUV) EN50082-1 CE
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Weight	3200 g
