Allied Telesis AT-9724TS Reference Manual

Each command is listed, in detail, in the following sections.
config bandwidth_control
Purpose Used to configure bandwidth control on a by-port basis.
Syntax config bandwidth_control [<portlist> | all] {rx_rate [no_limit | <value 1-999>] | tx_rate
[no_limit | <value 1-999>]}
Description The config bandwidth_control command is used to configure bandwidth on a by-port basis.
Parameters <portlist> – Specifies a range of ports to be configured.The port list is specified by listing the lowest switch
number and the beginning port number on that switch, separated by a colon.Then the highest switch number,
and the highest port number of the range (also separated by a colon) are specified.The beginning and end of
the port list range are separated by a dash. For example, 1:3 specifies switch number 1, port 3. 2:4 specifies
switch number 2, port 4. 1:3-2:4 specifies all of the ports between switch 1, port 3 and switch 2, port 4 – in
numerical order.
all – Choose this parameter to select all configurable ports.
rx_rate – Specifies that one of the parameters below (no_limit or <value 1-999>) will be applied to the rate at
which the above specified ports will be allowed to receive packets
no_limit – Specifies that there will be no limit on the rate of packets received by the above specified ports.
<value 1-999> – Specifies the packet limit, in Mbps, that the above ports will be allowed to receive.
tx_rate – Specifies that one of the parameters below (no_limit or <value 1-999>) will be applied to the rate at
which the above specified ports will be allowed to transmit packets.
no_limit – Specifies that there will be no limit on the rate of packets received by the above specified ports.
<value 1-999> – Specifies the packet limit, in Mbps, that the above ports will be allowed to receive.
Restrictions Only administrator-level users can issue this command.
Example usage:
To configure bandwidth control:
AT-9724TS:4# config bandwidth_control 1:1-1:10 tx_rate 10
Command: config bandwidth_control 1:1-1:10 tx_rate 10
S u c c e s s .
A T - 9 7 2 4 T S : 4 #
91
Allied Telesyn AT-9724TS High-Density Layer 3 Stackable Gigabit Ethernet Switch • Command Line Interface Reference Manual

Allied Telesis AT-9724TS Specifications

General

MAC address table	16000 entries
Packet buffer memory	2 MB
Maximum data transfer rate	88 Gbit/s
Full duplex	Yes
Dimensions (WxDxH)	440 x 210 x 44 mm
Power requirements	100-240V AC/50-60Hz
Management platform	SNMP, RMON
Networking features	IEEE 802.3 10T Ethernet, IEEE 802.3u 100TX Ethernet, IEEE 802.3ab 1000T Ethernet, IEEE 802.3z 1000X Ethernet
Connectivity technology	Wired
DHCP features	DHCP client
Security algorithms	SSH
Switch type	Managed
Switch layer	L3+
SFP/SFP+ slots quantity	4
Basic switching RJ-45 Ethernet ports quantity	24
Memory type	SDRAM / Flash
Flash memory	16 MB
Internal memory	256 MB
Power consumption (typical)	90 W
Certification	UL 1950 FCC Class A CSA 22.2 No. 950 EN55022 Class A EN 60950 (TUV) EN50082-1 CE
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Weight	3200 g
