ProtocolType_5 = 7
CASFILENAME_0='E_M_FGBWinkTable.dat'
CASFILENAME_1='E_M_FGDWinkTable.dat'
CASFILENAME_2='E_M_WinkTable.txt'
CasChannelIndex_5 =
‘0,0,0,1,1,1,2,2,2,0,0,0,1,1,1,0,1,2,0,2,1,2,2
,2’
CASDelimitersPaddingUsage_5 = 1
CAS table per channel group: Each channel group is
separated by a colon and each channel is separated by a
comma. The syntax is <x-y channel range>:<CAS table
index>, (e.g., "1-10:1,11-31:3"). Every B-channel (including 16
for E1) must belong to a channel group. Below is an example
for configuring an E1 CAS trunk (Trunk 5) with several CAS
variants:
ProtocolType_5 = 8
CASFILENAME_2='E1_R2D'
CASFILENAME_7= E_M_ImmediateTable_A-Bit.txt'
CasChannelIndex_5 = ‘1-10:2,11-20:7,21-31:2’
Notes:
To configure this parameter, the trunk must first be stopped.
Only one of these formats can be implemented; not both.
When this parameter is not configured, a single CAS table for
the entire trunk is used, configured by the parameter
CASTableIndex.
[CASTablesNum]
Defines how many CAS protocol configurations files are loaded.
The valid range is 1 to 8.
Note: For this parameter to take effect, a device reset is required.
CAS State Machines Parameters
Note: For configuring the CAS State Machine table using the Web interface, see 'Configuring CAS
State Machines' on page 282. The CAS state machine can be configured only through the Web-
based management tool.
Web: Generate Digit On Time
[CASStateMachineGenerate
DigitOnTime]
Generates digit on-time (in msec).
The value must be a positive value. The default is -1.
Web: Generate Inter Digit Time
[CASStateMachineGenerateI
nterDigitTime]
Generates digit off-time (in msec).
The value must be a positive value. The default is -1.
Web: DTMF Max Detection
Time
[CASStateMachineDTMFMax
OnDetectionTime]
Detects digit maximum on time (according to DSP detection
information event) in msec units.
The value must be a positive value. The default is -1.
Web: DTMF Min Detection
Time
[CASStateMachineDTMFMin
OnDetectionTime]
Detects digit minimum on time (according to DSP detection
information event) in msec units. The digit time length must be
longer than this value to receive a detection. Any number may be
used, but the value must be less than
CasStateMachineDTMFMaxOnDetectionTime.
The value must be a positive value. The default is -1.
Web: MAX Incoming Address
