3 - 30
Buttonhole and Pattern selecting mechanism
Application of Disassembly
Application
Application
1 Disassembly of BH stopper assy
1. Remove the BH change arm 1 from the BH stopper 2.
2. Remove the retaining ring E4 3, and then remove the BH stopper 2 from
the BH stopper holder assy 4.
2
3 4 1
2 Removal of Hexagon M4x40.5
1. Remove the hexagon M4x40.5 1.
1
